Investigating the Map Save File

Author

Message

DVader

20

Years of Service

User Offline

Joined: 28th Jan 2004

Location:

Profile

Posted: 2nd May 2019 18:27 Edited at: 2nd May 2019 19:25

Link

EDIT - So far all tests have proven GG is working fine with save files or at least with the ones I checked. I 'll leave the posts as is though.

Hi. I don't visit as often as I used to, but after a brief discussion in another thread, I decided to have a think about about it - the ongoing after awhile, my game slows down issue. Caused from my experience from just saving your level over and over and/or deleting objects etc.

This is just a starting point for anyone with the interest and time to spare.
I created a new blank map and saved it. Then I extracted the .fpm. Then I added a default building and saved and extracted again.
The first version of map.ele, which I'm pretty sure is the correct one reads thus:

+ Code Snippet

8[ ]

Nice and neat

I added the space between the square brackets as without it the text would not display

The second version with one object loaded looks like this:

+ Code Snippet

8              6ÿÉF  DRöÉF            Sandstone Structure (1)
appear.lua
default.lua
disappear.lua



    combat building_D.dds

effectbank\reloaded\apbr_basic.fx


            d           d

                 ÈB                   ÿÿÿÿ
U                                                                                  d   d   d          d



d


  ÈB

I'm guessing here, that the spaces are mainly quirks of loading it into notepad. Nowhere near as neat now though, although that isn't the problem really.

If I continued this, adding a few more objects to see how the file changes, then start deleting them, you would expect the data to be removed. I haven't got this far as yet as due to time restraints but I will continue and add another object and then try deleting one. If the file does not reflect this or leaves some junk behind then we know what the problem is.

For anyone interested in trying this out themselves and want to beat me to it you can extract your levels in winrar with the password mypassword. I'm pretty sure I'm not doing anything naughty here I believe it is fairly common knowledge. Any mods think this is not allowed, feel free to remove it.
@Teabone. I remembered it (the password)

I'll get back when I have looked a little more, or of course if someone is really in need of working this out, feel free to take the initiative from my very basic start point

As an aside. The file size of the bigger file (with one entity) still registers as the same size as the first one in Windows. Modern computers eh? lol.

Edit - Okay. I ended up not having to stop looking as I thought I was

I've tried adding another object and it added the relevant data. I then deleted both objects and checked. Back to the simple 8[] line. So, the element file is working just fine, at least from a very small test with no real stress making a real game would. They were just static entities as well so dynamic structures may be a cause or of course, not

If there is any issue with level saving slowly eating away at memory or speed, the elements one seems fine. How this could change with a proper complicated game map of course would be a lot more difficult and very slow to check using this step by step method. Also, different objects may cause problems. I used the first 2 default buildings built in to GG. Other items may cause issues possibly and could have a different story. The problem of allowing people other than TGC to make stuff

Although I have no evidence either way here, just eliminating stuff.

SPECS: Ryzen 1700 CPU. Nvidia 970GTX. 16 Gig Memory. Win 10.

PM Website

3com

10

Years of Service

User Offline

Joined: 18th May 2014

Location: Catalonia

Profile

Posted: 12th May 2019 11:39

Link

Quoted, ty 4 take the time for test it.

I don't have that issue so far, but if so, I'll use your step by step method.

Laptop: Lenovo - Intel(R) Celeron(R) CPU 1005M @ 1.90GHz

OS: Windows 10 (64) - Ram: 4 gb - Hd: 283 gb - Video card: Intel(R) HD Graphics
cpu mark: 10396.6
2d graphics mark: 947.9
3d graphics mark: 8310.9
memory mark 2584.8
Disk mark: 1146.3
Passmark rating: 3662.4

PM

Bored of the Rings

GameGuru Master

19

Years of Service

User Offline

Joined: 25th Feb 2005

Location: Middle Earth

Profile

Posted: 17th May 2019 11:40 Edited at: 17th May 2019 15:21

Link

if you want to probe further into the map.ele file and read it in, you can find the following code in M-Entity.cpp. it'svery much like the FPSC code and I used similar code for one of my tools when reading in entity placement info.

void entity_loadelementsdata ( void )
{
	//  Free any old elements
	entity_deleteelementsdata ( );

//  Uses elementfilename$ (element data from test game quick build - not from universe.ele created during full build)
	if (  t.elementsfilename_s == ""  )  t.elementsfilename_s = "levelbank\\testmap\\map.ele";

// load entity element list
	t.failedtoload=0;
	t.versionnumbersupported = 312;
	if ( FileExist(t.elementsfilename_s.Get()) == 1 )
	{
		OpenToRead (  1,t.elementsfilename_s.Get() );
		t.versionnumberload = ReadLong ( 1 );
		if (  t.versionnumberload<100 )
		{
			//  Pre-version data - development only
			g.entityelementlist=t.versionnumberload;
			t.versionnumberload=100;
		}
		else
		{
			g.entityelementlist = ReadLong ( 1 );
		}
		if (  t.versionnumberload <= t.versionnumbersupported )
		{
			if (  g.entityelementlist>0 )
			{
				UnDim (  t.entityelement );
				UnDim2 (  t.entityshadervar );
				UnDim (  t.entitydebug_s );
				g.entityelementmax=g.entityelementlist;
				Dim (  t.entityelement,g.entityelementmax );
				Dim2(  t.entityshadervar,g.entityelementmax, g.globalselectedshadermax  );
				Dim (  t.entitydebug_s,g.entityelementmax  );
				for ( t.e = 1 ; t.e<=  g.entityelementlist; t.e++ )
				{
					if ( t.game.runasmultiplayer == 1 ) steam_refresh ( );
					//  actual file data
					if (  t.versionnumberload >= 101 )
					{
						//  Version 1.01
						t.a = ReadLong ( 1 ); t.entityelement[t.e].maintype=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].bankindex=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].staticflag=t.a;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].x=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].y=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].z=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].rx=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].ry=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].rz=t.a_f;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.name_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aiinit_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aimain_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aidestroy_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isobjective=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.usekey_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.ifused_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.ifusednear_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.uniqueelement=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.texd_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.texaltd_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.effect_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.transparency=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].editorfixed=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset1_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnmax=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawndelay=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnqty=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.hurtfall=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.castshadow=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.reducetexture=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.speed=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aishoot_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.hasweapon_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.lives=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].spawn.max=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].spawn.delay=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].spawn.qty=t.a;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.scale=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.coneheight=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.coneangle=t.a_f;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.strength=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isimmobile=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.cantakeweapon=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.quantity=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.markerindex=t.a;
						t.a = ReadLong ( 1 ); t.dw=t.a ; t.dw=t.dw+0xFF000000 ; t.entityelement[t.e].eleprof.light.color=t.dw;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.light.range=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.trigger.stylecolor=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.trigger.waypointzoneindex=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.basedecal_s=t.a_s;
					}
					if (  t.versionnumberload >= 102 )
					{
						//  Version 1.02
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.rateoffire=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.damage=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.accuracy=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.reloadqty=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.fireiterations=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.lifespan=t.a;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.throwspeed=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.throwangle=t.a_f;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.bounceqty=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.explodeonhit=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.weaponisammo=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnupto=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnafterdelay=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnwhendead=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
					}
					if (  t.versionnumberload >= 103 )
					{
						//  Version 1.03 - V1 draft physics
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.physics=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phyweight=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phyfriction=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phyforcedamage=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.rotatethrow=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.explodable=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.explodedamage=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phydw4=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phydw5=t.a;
					}
					if (  t.versionnumberload >= 104 )
					{
						//  Version 1.04 - BETA4 extra field
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phyalways=t.a;
					}
					if (  t.versionnumberload >= 105 )
					{
						//  Version 1.05 - BETA8 extra fields
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawndelayrandom=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnqtyrandom=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnvel=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnvelrandom=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnangle=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnanglerandom=t.a;
					}
					if (  t.versionnumberload >= 106 )
					{
						//  Version 1.06 - BETA10 extra fields
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnatstart=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnlife=t.a;
					}
					if (  t.versionnumberload >= 107 )
					{
						//  FPSCV104RC8 - forgot to save infinilight index (dynamic lights in final build never worked)
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.light.index=t.a;
					}
					if (  t.versionnumberload >= 199 )
					{
						//  X10 EXTRAS - Ignored in X9
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
					}
					if (  t.versionnumberload >= 200 )
					{
						//  X10 EXTRAS 190707 - Ignored in X9
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
					}
					if (  t.versionnumberload >= 217 )
					{
						//  FPGC - 300710 - save new entity element data
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particleoverride=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.offsety=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.scale=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randomstartx=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randomstarty=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randomstartz=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.linearmotionx=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.linearmotiony=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.linearmotionz=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randommotionx=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randommotiony=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randommotionz=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.mirrormode=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.camerazshift=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.scaleonlyx=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.lifeincrement=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.alphaintensity=t.a;
					}
					if (  t.versionnumberload >= 218 )
					{
						//  V118 - 060810 - knxrb - Decal animation setting (Added animation choice setting).
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.animated=t.a;
					}
					if (  t.versionnumberload >= 301 )
					{
						//  Reloaded ALPHA 1.0045
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aiinitname_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aimainname_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aidestroyname_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aishootname_s=t.a_s;
					}
					if (  t.versionnumberload >= 302 )
					{
						//  Reloaded BETA 1.005
					}
					if (  t.versionnumberload >= 303 )
					{
						//  Reloaded BETA 1.007
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.animspeed=t.a;
					}
					if (  t.versionnumberload >= 304 )
					{
						//  Reloaded BETA 1.007-200514
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.conerange=t.a_f;
					}
					if (  t.versionnumberload >= 305 )
					{
						//  Reloaded BETA 1.0085
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].scalex=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].scaley=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].scalez=t.a_f;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.range=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.dropoff=t.a;
					}
					if (  t.versionnumberload >= 306 )
					{
						//  GameGuru 1.00.010
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isviolent=t.a;
					}
					if (  t.versionnumberload >= 307 )
					{
						//  GameGuru 1.00.020
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.teamfield=t.a;
					}
					if (  t.versionnumberload >= 308 )
					{
						//  GameGuru 1.01.001
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.usespotlighting=t.a;
					}
					if (  t.versionnumberload >= 309 )
					{
						//  GameGuru 1.01.002
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.lodmodifier=t.a;
					}
					if (  t.versionnumberload >= 310 )
					{
						//  GameGuru 1.133
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isocluder=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isocludee=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.colondeath=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.parententityindex=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.parentlimbindex=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset2_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset3_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset4_s=t.a_s;
					}
					if (  t.versionnumberload >= 311 )
					{
						//  GameGuru 1.133B
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.specularperc=t.a_f;
					}
					if (  t.versionnumberload >= 312 )
					{
						//  GameGuru 1.14 EBE
						t.a = ReadLong ( 1 ); t.entityelement[t.e].iHasParentIndex = t.a;
					}

//  fill in the blanks if load older version
					t.ttentid=t.entityelement[t.e].bankindex;
					if (  t.versionnumberload<103 )
					{
						//  Version 1.03 - V1 draft physics (-1 means calculate at entobj-loadtime)
						t.entityelement[t.e].eleprof.physics=t.entityprofile[t.ttentid].physics;
						t.entityelement[t.e].eleprof.phyweight=t.entityprofile[t.ttentid].phyweight;
						t.entityelement[t.e].eleprof.phyfriction=t.entityprofile[t.ttentid].phyfriction;
						t.entityelement[t.e].eleprof.phyforcedamage=t.entityprofile[t.ttentid].phyforcedamage;
						t.entityelement[t.e].eleprof.rotatethrow=t.entityprofile[t.ttentid].rotatethrow;
						t.entityelement[t.e].eleprof.explodable=t.entityprofile[t.ttentid].explodable;
						t.entityelement[t.e].eleprof.phydw3=0;
						t.entityelement[t.e].eleprof.phydw4=0;
						t.entityelement[t.e].eleprof.phydw5=0;
					}
					if (  t.versionnumberload<104 )
					{
						//  Version 1.04 - BETA4 extra field
						t.entityelement[t.e].eleprof.phyalways=t.entityprofile[t.ttentid].phyalways;
					}
					if (  t.versionnumberload<105 )
					{
						//  Version 1.05 - BETA8
						t.entityelement[t.e].eleprof.spawndelayrandom=t.entityprofile[t.ttentid].spawndelayrandom;
						t.entityelement[t.e].eleprof.spawnqtyrandom=t.entityprofile[t.ttentid].spawnqtyrandom;
						t.entityelement[t.e].eleprof.spawnvel=t.entityprofile[t.ttentid].spawnvel;
						t.entityelement[t.e].eleprof.spawnvelrandom=t.entityprofile[t.ttentid].spawnvelrandom;
						t.entityelement[t.e].eleprof.spawnangle=t.entityprofile[t.ttentid].spawnangle;
						t.entityelement[t.e].eleprof.spawnanglerandom=t.entityprofile[t.ttentid].spawnanglerandom;
					}
					if (  t.versionnumberload<106 )
					{
						//  Version 1.06 - BETA10
						t.entityelement[t.e].eleprof.spawnatstart=t.entityprofile[t.ttentid].spawnatstart;
						t.entityelement[t.e].eleprof.spawnlife=t.entityprofile[t.ttentid].spawnlife;
					}
					if (  t.versionnumberload<217 )
					{
						//  FPGC - 300710 - older levels dont use particle override
						t.entityelement[t.e].eleprof.particleoverride=0;
					}
					if (  t.versionnumberload<303 )
					{
						//  Reloaded BETA 1.007
						t.entityelement[t.e].eleprof.animspeed=t.entityprofile[t.ttentid].animspeed;
					}
					if (  t.versionnumberload<304 )
					{
						//  Reloaded BETA 1.007-200514
						t.entityelement[t.e].eleprof.conerange=t.entityprofile[t.ttentid].conerange;
					}
					if (  t.versionnumberload<306 )
					{
						//  GameGuru 1.00.010
						t.entityelement[t.e].eleprof.isviolent=t.entityprofile[t.ttentid].isviolent;
					}
					if (  t.versionnumberload<307 )
					{
						//  GameGuru 1.00.020
						t.entityelement[t.e].eleprof.teamfield=t.entityprofile[t.ttentid].teamfield;
					}
					if (  t.versionnumberload<310 )
					{
						//  GameGuru 1.133
						t.entityelement[t.e].eleprof.isocluder=t.entityprofile[t.ttentid].isocluder;
						t.entityelement[t.e].eleprof.isocludee=t.entityprofile[t.ttentid].isocludee;
						t.entityelement[t.e].eleprof.colondeath=t.entityprofile[t.ttentid].colondeath;
						t.entityelement[t.e].eleprof.parententityindex=t.entityprofile[t.ttentid].parententityindex;
						t.entityelement[t.e].eleprof.parentlimbindex=t.entityprofile[t.ttentid].parentlimbindex;
						t.entityelement[t.e].eleprof.soundset2_s=t.entityprofile[t.ttentid].soundset2_s;
						t.entityelement[t.e].eleprof.soundset3_s=t.entityprofile[t.ttentid].soundset3_s;
						t.entityelement[t.e].eleprof.soundset4_s=t.entityprofile[t.ttentid].soundset4_s;
					}
					if (  t.versionnumberload<311 )
					{
						//  GameGuru 1.133B
						t.entityelement[t.e].eleprof.specularperc=t.entityprofile[t.ttentid].specularperc;
					}
					if (  t.versionnumberload<312 )
					{
						//  GameGuru 1.14 EBE
						t.entityelement[t.e].iHasParentIndex = 0;
					}
					t.entityelement[t.e].entitydammult_f=1.0;
					t.entityelement[t.e].entityacc=1.0;

// 131115 - transparency control was removed from GG properties IDE, so ensure
					// it reflects the latest entity profile information (until we allow this value back in)
					t.entityelement[t.e].eleprof.transparency = t.entityprofile[t.ttentid].transparency;
				}
			}
		}
		else
		{
			t.failedtoload=1;
		}
		CloseFile (  1 );

// 050416 - remove any weapons from start marker if parental control, no weapon, no violence
		if ( g.quickparentalcontrolmode == 2 )
		{
			for ( t.e = 1 ; t.e <= g.entityelementlist; t.e++ )
			{
				t.entid = t.entityelement[t.e].bankindex;
				if (  t.entityprofile[t.entid].ismarker == 1 )
				{
					//  Player Start Marker Settings
					t.entityelement[t.e].eleprof.hasweapon_s = "";
					t.entityelement[t.e].eleprof.hasweapon = 0;
					t.entityelement[t.e].eleprof.quantity = 0;
					t.entityelement[t.e].eleprof.isviolent = 0;
				}
			}
		}

// entity AI replace (getting a level to work then disable the code until next time)
		if ( 0 )
		{
			bool bMissingScriptFoundAndReplaced = false;
			for ( t.e = 1 ; t.e<=  g.entityelementlist; t.e++ )
			{
				for ( t.tcheck = 1 ; t.tcheck<=  3; t.tcheck++ )
				{
					if (  t.tcheck == 1  )  t.tcheck_s = t.entityelement[t.e].eleprof.aimain_s;
					if (  t.tcheck == 2  )  t.tcheck_s = t.entityelement[t.e].eleprof.aiinit_s;
					if (  t.tcheck == 3  )  t.tcheck_s = t.entityelement[t.e].eleprof.aidestroy_s;
					t.ttry_s="";
					for ( t.nn = 1 ; t.nn<=  Len(t.tcheck_s.Get()); t.nn++ )
					{
						t.ttry_s=t.ttry_s+Mid(t.tcheck_s.Get(),t.nn);
						if (  (cstr(Mid(t.tcheck_s.Get(),t.nn)) == "\\" && cstr(Mid(t.tcheck_s.Get(),t.nn+1)) == "\\") || (cstr(Mid(t.tcheck_s.Get(),t.nn)) == "/" && cstr(Mid(t.tcheck_s.Get(),t.nn+1)) == "/") )
						{
							++t.nn;
						}
					}
					t.ttry_s=Lower(t.ttry_s.Get());
					if ( strlen(t.ttry_s.Get()) > 4 && FileExist(cstr(cstr("scriptbank\\")+t.ttry_s).Get()) == 0 )
					{
						if (  t.tcheck == 1 ) t.entityelement[t.e].eleprof.aimain_s = cstr(cstr("stories\\Cell Shaded\\")+cstr(t.ttry_s)).Get();
						if (  t.tcheck == 2 ) t.entityelement[t.e].eleprof.aiinit_s = cstr(cstr("stories\\Cell Shaded\\")+cstr(t.ttry_s)).Get();
						if (  t.tcheck == 3 ) t.entityelement[t.e].eleprof.aidestroy_s = cstr(cstr("stories\\Cell Shaded\\")+cstr(t.ttry_s)).Get();
						bMissingScriptFoundAndReplaced = true;
					}
				}
			}
		}

//  If replacement file active, can swap in new SCRIPT and SOUND references
		if (  Len(t.editor.replacefilepresent_s.Get())>1 )
		{
			//  now go through ELEPROF enrties to update any SCRIPTBANK references and SOUNDSET references
			for ( t.e = 1 ; t.e<=  g.entityelementlist; t.e++ )
			{
				for ( t.tcheck = 1 ; t.tcheck <= 6; t.tcheck++ )
				{
					if (  t.tcheck == 1  )  t.tcheck_s = t.entityelement[t.e].eleprof.aimain_s;
					if (  t.tcheck == 2  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset_s;
					if (  t.tcheck == 3  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset1_s;
					if (  t.tcheck == 4  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset2_s;
					if (  t.tcheck == 5  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset3_s;
					if (  t.tcheck == 6  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset4_s;
					t.ttry_s="";
					for ( t.nn = 1 ; t.nn<=  Len(t.tcheck_s.Get()); t.nn++ )
					{
						t.ttry_s=t.ttry_s+Mid(t.tcheck_s.Get(),t.nn);
						if (  (cstr(Mid(t.tcheck_s.Get(),t.nn)) == "\\" && cstr(Mid(t.tcheck_s.Get(),t.nn+1)) == "\\") || (cstr(Mid(t.tcheck_s.Get(),t.nn)) == "/" && cstr(Mid(t.tcheck_s.Get(),t.nn+1)) == "/") )
						{
							++t.nn;
						}
					}
					t.ttry_s=Lower(t.ttry_s.Get());
					for ( t.tt = 1 ; t.tt<=  t.treplacementmax; t.tt++ )
					{
						if (  t.replacements_s[t.tt][0] == t.ttry_s )
						{
							//  found entry we can replace
							if (  t.tcheck == 1 ) { t.entityelement[t.e].eleprof.aimain_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 2 ) { t.entityelement[t.e].eleprof.soundset_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 3 ) { t.entityelement[t.e].eleprof.soundset1_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 4 ) { t.entityelement[t.e].eleprof.soundset2_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 5 ) { t.entityelement[t.e].eleprof.soundset3_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 6 ) { t.entityelement[t.e].eleprof.soundset4_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
						}
					}
				}
			}
			//  free usages
			UnDim (  t.replacements_s );
		}
	}

//  and erase any elements that DO NOT have a valid profile (file moved/deleted)
	if (  t.failedtoload == 1 )
	{
		//  FPGC - 270410 - if entity binary from X10 (or just not supported), ensure NO entities!
		g.entityelementlist=0;
		g.entityelementmax=0;
	}
	else
	{
		for ( t.e = 1 ; t.e<=  g.entityelementlist; t.e++ )
		{
			t.entid=t.entityelement[t.e].bankindex;
			if (  t.entid>0 )
			{
				if (  t.entid>ArrayCount(t.entitybank_s) )
				{
					t.entityelement[t.e].bankindex=0;
				}
				else
				{
					if (  Len(t.entitybank_s[t.entid].Get()) == 0 )
					{
						//  030715 - but only erase if entity not a marker
						if (  t.entityprofile[t.entid].ismarker == 0 )
						{
							t.entityelement[t.e].bankindex=0;
						}
					}
				}
			}
		}
	}
}

+ Code Snippet

void entity_loadelementsdata ( void )
{
	//  Free any old elements
	entity_deleteelementsdata ( );

	//  Uses elementfilename$ (element data from test game quick build - not from universe.ele created during full build)
	if (  t.elementsfilename_s == ""  )  t.elementsfilename_s = "levelbank\\testmap\\map.ele";

	// load entity element list
	t.failedtoload=0;
	t.versionnumbersupported = 312;
	if ( FileExist(t.elementsfilename_s.Get()) == 1 )
	{
		OpenToRead (  1,t.elementsfilename_s.Get() );
		t.versionnumberload = ReadLong ( 1 );
		if (  t.versionnumberload<100 )
		{
			//  Pre-version data - development only
			g.entityelementlist=t.versionnumberload;
			t.versionnumberload=100;
		}
		else
		{
			g.entityelementlist = ReadLong ( 1 );
		}
		if (  t.versionnumberload <= t.versionnumbersupported )
		{
			if (  g.entityelementlist>0 )
			{
				UnDim (  t.entityelement );
				UnDim2 (  t.entityshadervar );
				UnDim (  t.entitydebug_s );
				g.entityelementmax=g.entityelementlist;
				Dim (  t.entityelement,g.entityelementmax );
				Dim2(  t.entityshadervar,g.entityelementmax, g.globalselectedshadermax  );
				Dim (  t.entitydebug_s,g.entityelementmax  );
				for ( t.e = 1 ; t.e<=  g.entityelementlist; t.e++ )
				{
					if ( t.game.runasmultiplayer == 1 ) steam_refresh ( );
					//  actual file data
					if (  t.versionnumberload >= 101 )
					{
						//  Version 1.01
						t.a = ReadLong ( 1 ); t.entityelement[t.e].maintype=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].bankindex=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].staticflag=t.a;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].x=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].y=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].z=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].rx=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].ry=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].rz=t.a_f;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.name_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aiinit_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aimain_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aidestroy_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isobjective=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.usekey_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.ifused_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.ifusednear_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.uniqueelement=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.texd_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.texaltd_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.effect_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.transparency=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].editorfixed=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset1_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnmax=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawndelay=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnqty=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.hurtfall=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.castshadow=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.reducetexture=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.speed=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aishoot_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.hasweapon_s=t.a_s;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.lives=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].spawn.max=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].spawn.delay=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].spawn.qty=t.a;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.scale=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.coneheight=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.coneangle=t.a_f;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.strength=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isimmobile=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.cantakeweapon=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.quantity=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.markerindex=t.a;
						t.a = ReadLong ( 1 ); t.dw=t.a ; t.dw=t.dw+0xFF000000 ; t.entityelement[t.e].eleprof.light.color=t.dw;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.light.range=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.trigger.stylecolor=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.trigger.waypointzoneindex=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.basedecal_s=t.a_s;
					}
					if (  t.versionnumberload >= 102 )
					{
						//  Version 1.02
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.rateoffire=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.damage=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.accuracy=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.reloadqty=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.fireiterations=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.lifespan=t.a;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.throwspeed=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.throwangle=t.a_f;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.bounceqty=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.explodeonhit=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.weaponisammo=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnupto=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnafterdelay=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnwhendead=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spare1=t.a;
					}
					if (  t.versionnumberload >= 103 )
					{
						//  Version 1.03 - V1 draft physics
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.physics=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phyweight=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phyfriction=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phyforcedamage=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.rotatethrow=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.explodable=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.explodedamage=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phydw4=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phydw5=t.a;
					}
					if (  t.versionnumberload >= 104 )
					{
						//  Version 1.04 - BETA4 extra field
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.phyalways=t.a;
					}
					if (  t.versionnumberload >= 105 )
					{
						//  Version 1.05 - BETA8 extra fields
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawndelayrandom=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnqtyrandom=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnvel=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnvelrandom=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnangle=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnanglerandom=t.a;
					}
					if (  t.versionnumberload >= 106 )
					{
						//  Version 1.06 - BETA10 extra fields
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnatstart=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.spawnlife=t.a;
					}
					if (  t.versionnumberload >= 107 )
					{
						//  FPSCV104RC8 - forgot to save infinilight index (dynamic lights in final build never worked)
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.light.index=t.a;
					}
					if (  t.versionnumberload >= 199 )
					{
						//  X10 EXTRAS - Ignored in X9
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
					}
					if (  t.versionnumberload >= 200 )
					{
						//  X10 EXTRAS 190707 - Ignored in X9
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
						t.a = ReadLong ( 1 );
					}
					if (  t.versionnumberload >= 217 )
					{
						//  FPGC - 300710 - save new entity element data
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particleoverride=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.offsety=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.scale=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randomstartx=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randomstarty=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randomstartz=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.linearmotionx=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.linearmotiony=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.linearmotionz=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randommotionx=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randommotiony=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.randommotionz=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.mirrormode=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.camerazshift=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.scaleonlyx=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.lifeincrement=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.alphaintensity=t.a;
					}
					if (  t.versionnumberload >= 218 )
					{
						//  V118 - 060810 - knxrb - Decal animation setting (Added animation choice setting).
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.particle.animated=t.a;
					}
					if (  t.versionnumberload >= 301 )
					{
						//  Reloaded ALPHA 1.0045
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aiinitname_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aimainname_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aidestroyname_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.aishootname_s=t.a_s;
					}
					if (  t.versionnumberload >= 302 )
					{
						//  Reloaded BETA 1.005
					}
					if (  t.versionnumberload >= 303 )
					{
						//  Reloaded BETA 1.007
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.animspeed=t.a;
					}
					if (  t.versionnumberload >= 304 )
					{
						//  Reloaded BETA 1.007-200514
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.conerange=t.a_f;
					}
					if (  t.versionnumberload >= 305 )
					{
						//  Reloaded BETA 1.0085
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].scalex=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].scaley=t.a_f;
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].scalez=t.a_f;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.range=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.dropoff=t.a;
					}
					if (  t.versionnumberload >= 306 )
					{
						//  GameGuru 1.00.010
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isviolent=t.a;
					}
					if (  t.versionnumberload >= 307 )
					{
						//  GameGuru 1.00.020
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.teamfield=t.a;
					}
					if (  t.versionnumberload >= 308 )
					{
						//  GameGuru 1.01.001
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.usespotlighting=t.a;
					}
					if (  t.versionnumberload >= 309 )
					{
						//  GameGuru 1.01.002
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.lodmodifier=t.a;
					}
					if (  t.versionnumberload >= 310 )
					{
						//  GameGuru 1.133
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isocluder=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.isocludee=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.colondeath=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.parententityindex=t.a;
						t.a = ReadLong ( 1 ); t.entityelement[t.e].eleprof.parentlimbindex=t.a;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset2_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset3_s=t.a_s;
						t.a_s = ReadString ( 1 ); t.entityelement[t.e].eleprof.soundset4_s=t.a_s;
					}
					if (  t.versionnumberload >= 311 )
					{
						//  GameGuru 1.133B
						t.a_f = ReadFloat ( 1 ); t.entityelement[t.e].eleprof.specularperc=t.a_f;
					}
					if (  t.versionnumberload >= 312 )
					{
						//  GameGuru 1.14 EBE
						t.a = ReadLong ( 1 ); t.entityelement[t.e].iHasParentIndex = t.a;
					}

					//  fill in the blanks if load older version
					t.ttentid=t.entityelement[t.e].bankindex;
					if (  t.versionnumberload<103 )
					{
						//  Version 1.03 - V1 draft physics (-1 means calculate at entobj-loadtime)
						t.entityelement[t.e].eleprof.physics=t.entityprofile[t.ttentid].physics;
						t.entityelement[t.e].eleprof.phyweight=t.entityprofile[t.ttentid].phyweight;
						t.entityelement[t.e].eleprof.phyfriction=t.entityprofile[t.ttentid].phyfriction;
						t.entityelement[t.e].eleprof.phyforcedamage=t.entityprofile[t.ttentid].phyforcedamage;
						t.entityelement[t.e].eleprof.rotatethrow=t.entityprofile[t.ttentid].rotatethrow;
						t.entityelement[t.e].eleprof.explodable=t.entityprofile[t.ttentid].explodable;
						t.entityelement[t.e].eleprof.phydw3=0;
						t.entityelement[t.e].eleprof.phydw4=0;
						t.entityelement[t.e].eleprof.phydw5=0;
					}
					if (  t.versionnumberload<104 )
					{
						//  Version 1.04 - BETA4 extra field
						t.entityelement[t.e].eleprof.phyalways=t.entityprofile[t.ttentid].phyalways;
					}
					if (  t.versionnumberload<105 )
					{
						//  Version 1.05 - BETA8
						t.entityelement[t.e].eleprof.spawndelayrandom=t.entityprofile[t.ttentid].spawndelayrandom;
						t.entityelement[t.e].eleprof.spawnqtyrandom=t.entityprofile[t.ttentid].spawnqtyrandom;
						t.entityelement[t.e].eleprof.spawnvel=t.entityprofile[t.ttentid].spawnvel;
						t.entityelement[t.e].eleprof.spawnvelrandom=t.entityprofile[t.ttentid].spawnvelrandom;
						t.entityelement[t.e].eleprof.spawnangle=t.entityprofile[t.ttentid].spawnangle;
						t.entityelement[t.e].eleprof.spawnanglerandom=t.entityprofile[t.ttentid].spawnanglerandom;
					}
					if (  t.versionnumberload<106 )
					{
						//  Version 1.06 - BETA10
						t.entityelement[t.e].eleprof.spawnatstart=t.entityprofile[t.ttentid].spawnatstart;
						t.entityelement[t.e].eleprof.spawnlife=t.entityprofile[t.ttentid].spawnlife;
					}
					if (  t.versionnumberload<217 )
					{
						//  FPGC - 300710 - older levels dont use particle override
						t.entityelement[t.e].eleprof.particleoverride=0;
					}
					if (  t.versionnumberload<303 )
					{
						//  Reloaded BETA 1.007
						t.entityelement[t.e].eleprof.animspeed=t.entityprofile[t.ttentid].animspeed;
					}
					if (  t.versionnumberload<304 )
					{
						//  Reloaded BETA 1.007-200514
						t.entityelement[t.e].eleprof.conerange=t.entityprofile[t.ttentid].conerange;
					}
					if (  t.versionnumberload<306 )
					{
						//  GameGuru 1.00.010
						t.entityelement[t.e].eleprof.isviolent=t.entityprofile[t.ttentid].isviolent;
					}
					if (  t.versionnumberload<307 )
					{
						//  GameGuru 1.00.020
						t.entityelement[t.e].eleprof.teamfield=t.entityprofile[t.ttentid].teamfield;
					}
					if (  t.versionnumberload<310 )
					{
						//  GameGuru 1.133
						t.entityelement[t.e].eleprof.isocluder=t.entityprofile[t.ttentid].isocluder;
						t.entityelement[t.e].eleprof.isocludee=t.entityprofile[t.ttentid].isocludee;
						t.entityelement[t.e].eleprof.colondeath=t.entityprofile[t.ttentid].colondeath;
						t.entityelement[t.e].eleprof.parententityindex=t.entityprofile[t.ttentid].parententityindex;
						t.entityelement[t.e].eleprof.parentlimbindex=t.entityprofile[t.ttentid].parentlimbindex;
						t.entityelement[t.e].eleprof.soundset2_s=t.entityprofile[t.ttentid].soundset2_s;
						t.entityelement[t.e].eleprof.soundset3_s=t.entityprofile[t.ttentid].soundset3_s;
						t.entityelement[t.e].eleprof.soundset4_s=t.entityprofile[t.ttentid].soundset4_s;
					}
					if (  t.versionnumberload<311 )
					{
						//  GameGuru 1.133B
						t.entityelement[t.e].eleprof.specularperc=t.entityprofile[t.ttentid].specularperc;
					}
					if (  t.versionnumberload<312 )
					{
						//  GameGuru 1.14 EBE
						t.entityelement[t.e].iHasParentIndex = 0;
					}
					t.entityelement[t.e].entitydammult_f=1.0;
					t.entityelement[t.e].entityacc=1.0;

					// 131115 - transparency control was removed from GG properties IDE, so ensure
					// it reflects the latest entity profile information (until we allow this value back in)
					t.entityelement[t.e].eleprof.transparency = t.entityprofile[t.ttentid].transparency;
				}
			}
		}
		else
		{
			t.failedtoload=1;
		}
		CloseFile (  1 );

		// 050416 - remove any weapons from start marker if parental control, no weapon, no violence
		if ( g.quickparentalcontrolmode == 2 )
		{
			for ( t.e = 1 ; t.e <= g.entityelementlist; t.e++ )
			{
				t.entid = t.entityelement[t.e].bankindex;
				if (  t.entityprofile[t.entid].ismarker == 1 )
				{
					//  Player Start Marker Settings
					t.entityelement[t.e].eleprof.hasweapon_s = "";
					t.entityelement[t.e].eleprof.hasweapon = 0;
					t.entityelement[t.e].eleprof.quantity = 0;
					t.entityelement[t.e].eleprof.isviolent = 0;
				}
			}
		}

		// entity AI replace (getting a level to work then disable the code until next time)
		if ( 0 )
		{
			bool bMissingScriptFoundAndReplaced = false;
			for ( t.e = 1 ; t.e<=  g.entityelementlist; t.e++ )
			{
				for ( t.tcheck = 1 ; t.tcheck<=  3; t.tcheck++ )
				{
					if (  t.tcheck == 1  )  t.tcheck_s = t.entityelement[t.e].eleprof.aimain_s;
					if (  t.tcheck == 2  )  t.tcheck_s = t.entityelement[t.e].eleprof.aiinit_s;
					if (  t.tcheck == 3  )  t.tcheck_s = t.entityelement[t.e].eleprof.aidestroy_s;
					t.ttry_s="";
					for ( t.nn = 1 ; t.nn<=  Len(t.tcheck_s.Get()); t.nn++ )
					{
						t.ttry_s=t.ttry_s+Mid(t.tcheck_s.Get(),t.nn);
						if (  (cstr(Mid(t.tcheck_s.Get(),t.nn)) == "\\" && cstr(Mid(t.tcheck_s.Get(),t.nn+1)) == "\\") || (cstr(Mid(t.tcheck_s.Get(),t.nn)) == "/" && cstr(Mid(t.tcheck_s.Get(),t.nn+1)) == "/") )
						{
							++t.nn;
						}
					}
					t.ttry_s=Lower(t.ttry_s.Get());
					if ( strlen(t.ttry_s.Get()) > 4 && FileExist(cstr(cstr("scriptbank\\")+t.ttry_s).Get()) == 0 )
					{
						if (  t.tcheck == 1 ) t.entityelement[t.e].eleprof.aimain_s = cstr(cstr("stories\\Cell Shaded\\")+cstr(t.ttry_s)).Get();
						if (  t.tcheck == 2 ) t.entityelement[t.e].eleprof.aiinit_s = cstr(cstr("stories\\Cell Shaded\\")+cstr(t.ttry_s)).Get();
						if (  t.tcheck == 3 ) t.entityelement[t.e].eleprof.aidestroy_s = cstr(cstr("stories\\Cell Shaded\\")+cstr(t.ttry_s)).Get();
						bMissingScriptFoundAndReplaced = true;
					}
				}
			}
		}

		//  If replacement file active, can swap in new SCRIPT and SOUND references
		if (  Len(t.editor.replacefilepresent_s.Get())>1 )
		{
			//  now go through ELEPROF enrties to update any SCRIPTBANK references and SOUNDSET references
			for ( t.e = 1 ; t.e<=  g.entityelementlist; t.e++ )
			{
				for ( t.tcheck = 1 ; t.tcheck <= 6; t.tcheck++ )
				{
					if (  t.tcheck == 1  )  t.tcheck_s = t.entityelement[t.e].eleprof.aimain_s;
					if (  t.tcheck == 2  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset_s;
					if (  t.tcheck == 3  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset1_s;
					if (  t.tcheck == 4  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset2_s;
					if (  t.tcheck == 5  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset3_s;
					if (  t.tcheck == 6  )  t.tcheck_s = t.entityelement[t.e].eleprof.soundset4_s;
					t.ttry_s="";
					for ( t.nn = 1 ; t.nn<=  Len(t.tcheck_s.Get()); t.nn++ )
					{
						t.ttry_s=t.ttry_s+Mid(t.tcheck_s.Get(),t.nn);
						if (  (cstr(Mid(t.tcheck_s.Get(),t.nn)) == "\\" && cstr(Mid(t.tcheck_s.Get(),t.nn+1)) == "\\") || (cstr(Mid(t.tcheck_s.Get(),t.nn)) == "/" && cstr(Mid(t.tcheck_s.Get(),t.nn+1)) == "/") )
						{
							++t.nn;
						}
					}
					t.ttry_s=Lower(t.ttry_s.Get());
					for ( t.tt = 1 ; t.tt<=  t.treplacementmax; t.tt++ )
					{
						if (  t.replacements_s[t.tt][0] == t.ttry_s )
						{
							//  found entry we can replace
							if (  t.tcheck == 1 ) { t.entityelement[t.e].eleprof.aimain_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 2 ) { t.entityelement[t.e].eleprof.soundset_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 3 ) { t.entityelement[t.e].eleprof.soundset1_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 4 ) { t.entityelement[t.e].eleprof.soundset2_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 5 ) { t.entityelement[t.e].eleprof.soundset3_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
							if (  t.tcheck == 6 ) { t.entityelement[t.e].eleprof.soundset4_s = t.replacements_s[t.tt][1]  ; t.tt = t.treplacementmax+1; }
						}
					}
				}
			}
			//  free usages
			UnDim (  t.replacements_s );
		}
	}

	//  and erase any elements that DO NOT have a valid profile (file moved/deleted)
	if (  t.failedtoload == 1 )
	{
		//  FPGC - 270410 - if entity binary from X10 (or just not supported), ensure NO entities!
		g.entityelementlist=0;
		g.entityelementmax=0;
	}
	else
	{
		for ( t.e = 1 ; t.e<=  g.entityelementlist; t.e++ )
		{
			t.entid=t.entityelement[t.e].bankindex;
			if (  t.entid>0 )
			{
				if (  t.entid>ArrayCount(t.entitybank_s) )
				{
					t.entityelement[t.e].bankindex=0;
				}
				else
				{
					if (  Len(t.entitybank_s[t.entid].Get()) == 0 )
					{
						//  030715 - but only erase if entity not a marker
						if (  t.entityprofile[t.entid].ismarker == 0 )
						{
							t.entityelement[t.e].bankindex=0;
						}
					}
				}
			}
		}
	}
}

I'm going to read this data in as I have some ideas floating around in my head.

so output so far is thus based on a blank map with a placement of 2 entities, a building and a wizard character:

+ Code Snippet

Versionnumberload: 312
g_entityelementlist: 2
entityelement(e).maintype: 1
entityelement(e).bankindex: 1
entityelement(e).staticflag: 1
entityelement(e).x: 25316.2128906
entityelement(e).y: 600
entityelement(e).z: 25799.4179688
entityelement(e).rx: 0
entityelement(e).ry: 0
entityelement(e).rz: 0
entityelement(e).maintype: 2037672259
entityelement(e).bankindex: 1818318624
entityelement(e).staticflag: 1953701996
entityelement(e).x: 1.10210893925e+024
entityelement(e).y: 6.81079663625e-033
entityelement(e).z: 7.09650613007e+022
entityelement(e).rx: 8.43572926905e+026
entityelement(e).ry: 6.80723268431e-033
entityelement(e).rz: 4.7425011424e+030

current DBPro code is :

failedtoload=0
versionnumbersupported = 312

type elements
	maintype as dword
	bankindex as dword
	staticflag as dword
	x	as float
	y	as float
	z	as float
	rx	as float
	ry	as float
	rz	as float
endtype

a as dword
a_f as float
a_s as string

global g_entityelementlist
global g_entityelementmax
global g_globalselectedshadermax

`src$="C:\temp\gg_work_out\map.ele"
src$="map.ele"

if file exist("testout.txt")=1 then delete file "testout.txt"
open to write 2,"testout.txt"
open to read 1,src$
`make memblock from file 1,1
read long 1,versionnumberload
write string 2, "Versionnumberload: "+str$(versionnumberload)
read long 1,g_entityelementlist
write string 2, "g_entityelementlist: "+str$(g_entityelementlist)

// condition (1)
if versionnumberload <= versionnumbersupported

// condiiton (2)
	if g_entityelementlist>0

undim entityelement()
		undim entityshadervar()
		undim entitydebug_s()
		g_entityelementmax=g_entityelementlist
		dim entityelement(g_entityelementmax) as elements
		dim entityshadervar(g_entityelementmax,g_globalselectedshadermax)
		dim entitydebug_s(g_entityelementmax)

for e= 1 to g_entityelementlist
					`if ( t.game.runasmultiplayer == 1 ) steam_refresh ( );
					//  actual file data
					if versionnumberload >= 101
						//  Version 1.01
						`Read Long 1, entityelement(e).maintype
						read long 1,a : entityelement(e).maintype = a
						write string 2, "entityelement(e).maintype: "+str$(entityelement(e).maintype)
						read long 1,a : entityelement(e).bankindex = a
						write string 2, "entityelement(e).bankindex: "+str$(entityelement(e).bankindex)
						read long 1,a : entityelement(e).staticflag = a
						write string 2, "entityelement(e).staticflag: "+str$(entityelement(e).staticflag)
						read float 1,a_f : entityelement(e).x=a_f
						write string 2, "entityelement(e).x: "+str$(entityelement(e).x)
						read float 1,a_f : entityelement(e).y=a_f
						write string 2, "entityelement(e).y: "+str$(entityelement(e).y)
						read float 1,a_f : entityelement(e).z=a_f
						write string 2, "entityelement(e).z: "+str$(entityelement(e).z)
						read float 1,a_f : entityelement(e).rx=a_f
						write string 2, "entityelement(e).rx: "+str$(entityelement(e).rx)
						read float 1,a_f : entityelement(e).ry=a_f
						write string 2, "entityelement(e).ry: "+str$(entityelement(e).ry)
						read float 1,a_f : entityelement(e).rz=a_f
						write string 2, "entityelement(e).rz: "+str$(entityelement(e).rz)

					endif

next e

endif // end of condition (2)
endif // end of condition (1)

+ Code Snippet

failedtoload=0
versionnumbersupported = 312

type elements
	maintype as dword
	bankindex as dword
	staticflag as dword
	x	as float
	y	as float
	z	as float
	rx	as float
	ry	as float
	rz	as float
endtype

a as dword
a_f as float
a_s as string

global g_entityelementlist
global g_entityelementmax
global g_globalselectedshadermax

`src$="C:\temp\gg_work_out\map.ele"
src$="map.ele"

if file exist("testout.txt")=1 then delete file "testout.txt"
open to write 2,"testout.txt"
open to read 1,src$
`make memblock from file 1,1
read long 1,versionnumberload
write string 2, "Versionnumberload: "+str$(versionnumberload)
read long 1,g_entityelementlist
write string 2, "g_entityelementlist: "+str$(g_entityelementlist)

// condition (1)
if versionnumberload <= versionnumbersupported

	// condiiton (2)
	if g_entityelementlist>0

		undim entityelement()
		undim entityshadervar()
		undim entitydebug_s()
		g_entityelementmax=g_entityelementlist
		dim entityelement(g_entityelementmax) as elements
		dim entityshadervar(g_entityelementmax,g_globalselectedshadermax)
		dim entitydebug_s(g_entityelementmax)


				for e= 1 to g_entityelementlist
					`if ( t.game.runasmultiplayer == 1 ) steam_refresh ( );
					//  actual file data
					if versionnumberload >= 101
						//  Version 1.01
						`Read Long 1, entityelement(e).maintype
						read long 1,a : entityelement(e).maintype = a
						write string 2, "entityelement(e).maintype: "+str$(entityelement(e).maintype)
						read long 1,a : entityelement(e).bankindex = a
						write string 2, "entityelement(e).bankindex: "+str$(entityelement(e).bankindex)
						read long 1,a : entityelement(e).staticflag = a
						write string 2, "entityelement(e).staticflag: "+str$(entityelement(e).staticflag)
						read float 1,a_f : entityelement(e).x=a_f
						write string 2, "entityelement(e).x: "+str$(entityelement(e).x)
						read float 1,a_f : entityelement(e).y=a_f
						write string 2, "entityelement(e).y: "+str$(entityelement(e).y)
						read float 1,a_f : entityelement(e).z=a_f
						write string 2, "entityelement(e).z: "+str$(entityelement(e).z)
						read float 1,a_f : entityelement(e).rx=a_f
						write string 2, "entityelement(e).rx: "+str$(entityelement(e).rx)
						read float 1,a_f : entityelement(e).ry=a_f
						write string 2, "entityelement(e).ry: "+str$(entityelement(e).ry)
						read float 1,a_f : entityelement(e).rz=a_f
						write string 2, "entityelement(e).rz: "+str$(entityelement(e).rz)

					endif

				next e

	endif // end of condition (2)
endif // end of condition (1)

just a matter of building the code up a bit at a time from the C code.

Professional Programmer: Languages- SAS (Statistical Analysis Software) , C++, C#, VB, SQL, PL-SQL, JavaScript, HTML, Three.js, Darkbasic Pro (still love this language), Purebasic, others
Hardware: Dell Precision 490; AMD Radeon HD 7570; 12GB.

PM Website

DVader

20

Years of Service

User Offline

Joined: 28th Jan 2004

Location:

Profile

Posted: 17th May 2019 14:40

Link

Not really done much C++ programming (I dabbled with the Dark Basic version for a day or two I think. Was it Dark Studio?). This looks a really big load routine from a quick glance. I'm guessing it's doing all the things we expect in there like truncating the file down etc. When the sun has gone in, I'll have a proper look and see if I can understand anything here, lol.

SPECS: Ryzen 1700 CPU. Nvidia 970GTX. 16 Gig Memory. Win 10.

PM Website

Bored of the Rings

GameGuru Master

19

Years of Service

User Offline

Joined: 25th Feb 2005

Location: Middle Earth

Profile

Posted: 17th May 2019 14:43 Edited at: 17th May 2019 15:19

Link

all it's doing is reading in DWORDs (Long) , floats, strings etc and assigning them to a variable and storing them in a structured array, so I'm doing a quick test proggy to read in the file, not yet complete in DBPro for a bit of fun, see what comes out in a debug file. Of course, there is probably a ton of other stuff going on:

+ Code Snippet

failedtoload=0
versionnumbersupported = 312

global g_entityelementlist
global g_entityelementmax
global g_globalselectedshadermax

`src$="C:\temp\gg_work_out\map.ele"
src$="map.ele"

if file exist("testout.txt")=1 then delete file "testout.txt"
open to write 2,"testout.txt"
open to read 1,src$
`make memblock from file 1,1
read long 1,versionnumberload
write string 2, "Versionnumberload: "+str$(versionnumberload)
read long 1,g_entityelementlist
write string 2, "g_entityelementlist: "+str$(g_entityelementlist)

// condition (1)
if versionnumberload <= versionnumbersupported

	// condiiton (2)
	if g_entityelementlist>0

		undim entityelement()
		undim entityshadervar()
		undim entitydebug_s()
		g_entityelementmax=g_entityelementlist
		dim entityelement(g_entityelementmax)
		dim entityshadervar(g_entityelementmax,g_globalselectedshadermax)
		dim entitydebug_s(g_entityelementmax)

	endif // end of condition (2)
endif // end of condition (1)



close file 1
close file 2

Professional Programmer: Languages- SAS (Statistical Analysis Software) , C++, C#, VB, SQL, PL-SQL, JavaScript, HTML, Three.js, Darkbasic Pro (still love this language), Purebasic, others
Hardware: Dell Precision 490; AMD Radeon HD 7570; 12GB.

PM Website

Bored of the Rings

GameGuru Master

19

Years of Service

User Offline

Joined: 25th Feb 2005

Location: Middle Earth

Profile

Posted: 19th May 2019 09:47 Edited at: 19th May 2019 10:00

Link

anyway, for those that have DBPro and want to view readable content of the map.ele file, here is the code:

failedtoload=0
versionnumbersupported = 312

type light_elements
	color as dword
	range as dword
	index as dword
endtype

type trigger_elements
	stylecolor as dword
	waypointzoneindex as dword
endtype

type particle_elements
	offsety as dword
	scale as dword
	randomstartx as dword
	randomstarty as dword
	randomstartz as dword
	linearmotionx as dword
	linearmotiony as dword
	linearmotionz as dword
	randommotionx as dword
	randommotiony as dword
	randommotionz as dword
	mirrormode as dword
	camerazshift as dword
	scaleonlyx as dword
	lifeincrement as dword
	alphaintensity as dword
	animated as dword
endtype

type eleprof_elements
	name_s as string
	aiinit_s as string
	aimain_s as string
	aidestroy_s as string
	isobjective as dword
	usekey_s as string
	ifused_s as string
	ifusednear_s as string
	uniqueelement as dword
	texd_s as string
	texaltd_s as string
	effect_s as string
	transparency as dword
	soundset_s as string
	soundset1_s as string
	spawnmax as dword
	spawndelay as dword
	spawnqty as dword
	hurtfall as dword
	castshadow as dword
	reducetexture as dword
	speed=t.a as dword
	aishoot_s as string
	hasweapon_s as string
	lives as dword
	scale as float
	coneheight as float
	coneangle as float
	strength as dword
	isimmobile as dword
	cantakeweapon as dword
	quantity as dword
	markerindex as dword
	light as light_elements
	trigger as trigger_elements
	basedecal_s as string
	rateoffire as dword
	damage as dword
	accuracy as dword
	reloadqty as dword
	fireiterations as dword
	lifespan as dword
	throwspeed as float
	throwangle as float
	bounceqty as dword
	explodeonhit as dword
	weaponisammo as dword
	spawnupto as dword
	spawnafterdelay as dword
	spawnwhendead as dword
	spare1 as dword
	physics as dword
	phyweight as dword
	phyfriction as dword
	phyforcedamage as dword
	rotatethrow as dword
	explodable as dword
	explodedamage as dword
	phydw4 as dword
	phydw5 as dword
	phyalways as dword
	spawndelayrandom as dword
	spawnqtyrandom as dword
	spawnvel as dword
	spawnvelrandom as dword
	spawnangle as dword
	spawnanglerandom as dword
	spawnatstart as dword
	spawnlife as dword
	particleoverride as dword
	particle as particle_elements
	aiinitname_s as string
	aimainname_s as string
	aidestroyname_s as string
	aishootname_s as string
	animspeed as dword
	conerange as float
	range as dword
	dropoff as dword
	isviolent as dword
	teamfield as dword
	usespotlighting as dword
	lodmodifier as dword
	isocluder as dword
	isocludee as dword
	colondeath as dword
	parententityindex as dword
	parentlimbindex as dword
	soundset2_s as string
	soundset3_s as string
	soundset4_s as string
	specularperc as float
endtype

type spawn_elements
	max as dword
	delay as dword
	qty as dword
endtype

type elements
	maintype as dword
	bankindex as dword
	staticflag as dword
	x	as float
	y	as float
	z	as float
	rx	as float
	ry	as float
	rz	as float
	eleprof as eleprof_elements
	editorfixed as dword
	lives as dword
	spawn as spawn_elements
	scalex as float
	scaley as float
	scalez as float
	iHasParentIndex as dword
endtype

a as dword
a_f as float
a_s as string
dw as dword

global g_entityelementlist
global g_entityelementmax
global g_globalselectedshadermax

`src$="C:\temp\gg_work_out\map.ele"
src$="map.ele"

if file exist("mapele.txt")=1 then delete file "mapele.txt"
open to write 2,"mapele.txt"
open to read 1,src$
read long 1,versionnumberload
write string 2, "Versionnumberload: "+str$(versionnumberload)
read long 1,g_entityelementlist
write string 2, "g_entityelementlist: "+str$(g_entityelementlist)

if versionnumberload <= versionnumbersupported

if g_entityelementlist>0

undim entityelement()
		`undim entityshadervar()
		`undim entitydebug_s()
		g_entityelementmax=g_entityelementlist
		dim entityelement(g_entityelementmax) as elements
		`dim entityshadervar(g_entityelementmax,g_globalselectedshadermax)
		`dim entitydebug_s(g_entityelementmax)

for e= 1 to g_entityelementlist
					`if ( t.game.runasmultiplayer == 1 ) steam_refresh ( );
					//  actual file data
					if versionnumberload >= 101
						//  Version 1.01
						read long 1,a : entityelement(e).maintype = a
						write string 2, "entityelement(e).maintype: "+str$(entityelement(e).maintype)
						read long 1,a : entityelement(e).bankindex = a
						write string 2, "entityelement(e).bankindex: "+str$(entityelement(e).bankindex)
						read long 1,a : entityelement(e).staticflag = a
						write string 2, "entityelement(e).staticflag: "+str$(entityelement(e).staticflag)
						read float 1,a_f : entityelement(e).x=a_f
						write string 2, "entityelement(e).x: "+str$(entityelement(e).x)
						read float 1,a_f : entityelement(e).y=a_f
						write string 2, "entityelement(e).y: "+str$(entityelement(e).y)
						read float 1,a_f : entityelement(e).z=a_f
						write string 2, "entityelement(e).z: "+str$(entityelement(e).z)
						read float 1,a_f : entityelement(e).rx=a_f
						write string 2, "entityelement(e).rx: "+str$(entityelement(e).rx)
						read float 1,a_f : entityelement(e).ry=a_f
						write string 2, "entityelement(e).ry: "+str$(entityelement(e).ry)
						read float 1,a_f : entityelement(e).rz=a_f
						write string 2, "entityelement(e).rz: "+str$(entityelement(e).rz)
						read string 1,a_s : entityelement(e).eleprof.name_s=a_s
						write string 2, "entityelement(e).eleprof.name_s: "+entityelement(e).eleprof.name_s
						read string 1,a_s : entityelement(e).eleprof.aiinit_s=a_s
						write string 2, "entityelement(e).eleprof.aiinit_s: "+entityelement(e).eleprof.aiinit_s
						read string 1,a_s : entityelement(e).eleprof.aimain_s=a_s
						write string 2, "entityelement(e).eleprof.aimain_s: "+entityelement(e).eleprof.aimain_s
						read string 1,a_s : entityelement(e).eleprof.aidestroy_s=a_s
						write string 2, "entityelement(e).eleprof.aidestroy_s: "+entityelement(e).eleprof.aidestroy_s
						read long 1,a : entityelement(e).eleprof.isobjective=a
						write string 2, "entityelement(e).eleprof.isobjective: "+str$(entityelement(e).eleprof.isobjective)
						read string 1,a_s : entityelement(e).eleprof.usekey_s=a_s
						write string 2, "entityelement(e).eleprof.usekey_s: "+entityelement(e).eleprof.usekey_s
						read string 1,a_s : entityelement(e).eleprof.ifused_s=a_s
						write string 2, "entityelement(e).eleprof.ifused_s: "+entityelement(e).eleprof.ifused_s
						read string 1,a_s : entityelement(e).eleprof.ifusednear_s=a_s
						write string 2, "entityelement(e).eleprof.ifusednear_s: "+entityelement(e).eleprof.ifusednear_s
						read long 1,a : entityelement(e).eleprof.uniqueelement=a
						write string 2, "entityelement(e).eleprof.uniqueelement: "+str$(entityelement(e).eleprof.uniqueelement)
						read string 1,a_s : entityelement(e).eleprof.texd_s=a_s
						write string 2, "entityelement(e).eleprof.texd_s: "+entityelement(e).eleprof.texd_s
						read string 1,a_s : entityelement(e).eleprof.texaltd_s=a_s
						write string 2, "entityelement(e).eleprof.texaltd_s: "+entityelement(e).eleprof.texaltd_s
						read string 1,a_s : entityelement(e).eleprof.effect_s=a_s
						write string 2, "entityelement(e).eleprof.effect_s: "+entityelement(e).eleprof.effect_s
						read long 1,a : entityelement(e).eleprof.transparency=a
						write string 2, "entityelement(e).eleprof.transparency: "+str$(entityelement(e).eleprof.transparency)
						read long 1,a : entityelement(e).editorfixed=a
						write string 2, "entityelement(e).editorfixed: "+str$(entityelement(e).editorfixed)
						read string 1,a_s : entityelement(e).eleprof.soundset_s=a_s
						write string 2, "entityelement(e).eleprof.soundset_s: "+entityelement(e).eleprof.soundset_s
						read string 1,a_s : entityelement(e).eleprof.soundset1_s=a_s
						write string 2, "entityelement(e).eleprof.soundset1_s: "+entityelement(e).eleprof.soundset1_s
						read long 1,a : entityelement(e).eleprof.spawnmax=a
						write string 2, "entityelement(e).eleprof.spawnmax: "+str$(entityelement(e).eleprof.spawnmax)
						read long 1,a : entityelement(e).eleprof.spawndelay=a
						write string 2, "entityelement(e).eleprof.spawndelay: "+str$(entityelement(e).eleprof.spawndelay)
						read long 1,a : entityelement(e).eleprof.spawnqty=a
						write string 2, "entityelement(e).eleprof.spawnqty: "+str$(entityelement(e).eleprof.spawnqty)
						read long 1,a : entityelement(e).eleprof.hurtfall=a
						write string 2, "entityelement(e).eleprof.hurtfall: "+str$(entityelement(e).eleprof.hurtfall)
						read long 1,a : entityelement(e).eleprof.castshadow=a
						write string 2, "entityelement(e).eleprof.castshadow: "+str$(entityelement(e).eleprof.castshadow)
						read long 1,a : entityelement(e).eleprof.reducetexture=a
						write string 2, "entityelement(e).eleprof.reducetexture: "+str$(entityelement(e).eleprof.reducetexture)
						read long 1,a : entityelement(e).eleprof.speed=a
						write string 2, "entityelement(e).eleprof.speed: "+str$(entityelement(e).eleprof.speed)
						read string 1,a_s : entityelement(e).eleprof.aishoot_s=a_s
						write string 2, "entityelement(e).eleprof.aishoot_s: "+entityelement(e).eleprof.aishoot_s
						read string 1,a_s : entityelement(e).eleprof.hasweapon_s=a_s
						write string 2, "entityelement(e).eleprof.hasweapon_s: "+entityelement(e).eleprof.hasweapon_s
						read long 1,a : entityelement(e).eleprof.lives=a
						write string 2, "entityelement(e).eleprof.lives: "+str$(entityelement(e).eleprof.lives)
						read long 1,a : entityelement(e).spawn.max=a
						write string 2, "entityelement(e).spawn.max: "+str$(entityelement(e).spawn.max)
						read long 1,a : entityelement(e).spawn.delay=a
						write string 2, "entityelement(e).spawn.delay: "+str$(entityelement(e).spawn.delay)
						read long 1,a : entityelement(e).spawn.qty=a
						write string 2, "entityelement(e).spawn.qty: "+str$(entityelement(e).spawn.qty)
						read float 1,a_f : entityelement(e).eleprof.scale=a_f
						write string 2, "entityelement(e).eleprof.scale: "+str$(entityelement(e).eleprof.scale)
						read float 1,a_f : entityelement(e).eleprof.coneheight=a_f
						write string 2, "entityelement(e).eleprof.coneheight: "+str$(entityelement(e).eleprof.coneheight)
						read float 1,a_f : entityelement(e).eleprof.coneangle=a_f
						write string 2, "entityelement(e).eleprof.coneangle: "+str$(entityelement(e).eleprof.coneangle)
						read long 1,a : entityelement(e).eleprof.strength=a
						write string 2, "entityelement(e).eleprof.strength: "+str$(entityelement(e).eleprof.strength)
						read long 1,a : entityelement(e).eleprof.isimmobile=a
						write string 2, "entityelement(e).eleprof.isimmobile: "+str$(entityelement(e).eleprof.isimmobile)
						read long 1,a : entityelement(e).eleprof.cantakeweapon=a
						write string 2, "entityelement(e).eleprof.cantakeweapon: "+str$(entityelement(e).eleprof.cantakeweapon)
						read long 1,a : entityelement(e).eleprof.quantity=a
						write string 2, "entityelement(e).eleprof.quantity: "+str$(entityelement(e).eleprof.quantity)
						read long 1,a : entityelement(e).eleprof.markerindex=a
						write string 2, "entityelement(e).eleprof.markerindex: "+str$(entityelement(e).eleprof.markerindex)
						read long 1,a : dw=a : dw=dw+0xFF000000 : entityelement(e).eleprof.light.color=dw
						write string 2, "entityelement(e).eleprof.light.color: "+str$(entityelement(e).eleprof.light.color)
						read long 1,a : entityelement(e).eleprof.light.range=a
						write string 2, "entityelement(e).eleprof.light.range: "+str$(entityelement(e).eleprof.light.range)
						read long 1,a : entityelement(e).eleprof.trigger.stylecolor=a
						write string 2, "entityelement(e).eleprof.trigger.stylecolor: "+str$(entityelement(e).eleprof.trigger.stylecolor)
						read long 1,a : entityelement(e).eleprof.trigger.waypointzoneindex=a
						write string 2, "entityelement(e).eleprof.trigger.waypointzoneindex: "+str$(entityelement(e).eleprof.trigger.waypointzoneindex)
						read string 1,a_s : entityelement(e).eleprof.basedecal_s=a_s
						write string 2, "entityelement(e).eleprof.basedecal_s: "+entityelement(e).eleprof.basedecal_s
					endif

					if versionnumberload >= 102
						//  Version 1.02
						read long 1,a : entityelement(e).eleprof.rateoffire=a
						write string 2, "entityelement(e).eleprof.rateoffire: "+str$(entityelement(e).eleprof.rateoffire)
						read long 1,a : entityelement(e).eleprof.damage=a
						write string 2, "entityelement(e).eleprof.damage: "+str$(entityelement(e).eleprof.damage)
						read long 1,a : entityelement(e).eleprof.accuracy=a
						write string 2, "entityelement(e).eleprof.accuracy: "+str$(entityelement(e).eleprof.accuracy)
						read long 1,a : entityelement(e).eleprof.reloadqty=a
						write string 2, "entityelement(e).eleprof.reloadqty: "+str$(entityelement(e).eleprof.reloadqty)
						read long 1,a : entityelement(e).eleprof.fireiterations=a
						write string 2, "entityelement(e).eleprof.fireiterations: "+str$(entityelement(e).eleprof.fireiterations)
						read long 1,a : entityelement(e).eleprof.lifespan=a
						write string 2, "entityelement(e).eleprof.lifespan: "+str$(entityelement(e).eleprof.lifespan)
						read float 1,a_f : entityelement(e).eleprof.throwspeed=a_f
						write string 2, "entityelement(e).eleprof.throwspeed: "+str$(entityelement(e).eleprof.throwspeed)
						read float 1,a_f : entityelement(e).eleprof.throwangle=a_f
						write string 2, "entityelement(e).eleprof.throwangle: "+str$(entityelement(e).eleprof.throwangle)
						read long 1,a : entityelement(e).eleprof.bounceqty=a
						write string 2, "entityelement(e).eleprof.bounceqty: "+str$(entityelement(e).eleprof.bounceqty)
						read long 1,a : entityelement(e).eleprof.explodeonhit=a
						write string 2, "entityelement(e).eleprof.explodeonhit: "+str$(entityelement(e).eleprof.explodeonhit)
						read long 1,a : entityelement(e).eleprof.weaponisammo=a
						write string 2, "entityelement(e).eleprof.weaponisammo: "+str$(entityelement(e).eleprof.weaponisammo)
						read long 1,a : entityelement(e).eleprof.spawnupto=a
						write string 2, "entityelement(e).eleprof.spawnupto: "+str$(entityelement(e).eleprof.spawnupto)
						read long 1,a : entityelement(e).eleprof.spawnafterdelay=a
						write string 2, "entityelement(e).eleprof.spawnafterdelay: "+str$(entityelement(e).eleprof.spawnafterdelay)
						read long 1,a : entityelement(e).eleprof.spawnwhendead=a
						write string 2, "entityelement(e).eleprof.spawnwhendead: "+str$(entityelement(e).eleprof.spawnwhendead)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
					endif

if versionnumberload >= 103
						//  Version 1.03

read long 1,a : entityelement(e).eleprof.physics=a
						write string 2, "entityelement(e).eleprof.physics: "+str$(entityelement(e).eleprof.physics)
						read long 1,a : entityelement(e).eleprof.phyweight=a
						write string 2, "entityelement(e).eleprof.phyweight: "+str$(entityelement(e).eleprof.phyweight)
						read long 1,a : entityelement(e).eleprof.phyfriction=a
						write string 2, "entityelement(e).eleprof.phyfriction: "+str$(entityelement(e).eleprof.phyfriction)
						read long 1,a : entityelement(e).eleprof.phyforcedamage=a
						write string 2, "entityelement(e).eleprof.phyforcedamage: "+str$(entityelement(e).eleprof.phyforcedamage)
						read long 1,a : entityelement(e).eleprof.rotatethrow=a
						write string 2, "entityelement(e).eleprof.rotatethrow: "+str$(entityelement(e).eleprof.rotatethrow)
						read long 1,a : entityelement(e).eleprof.explodable=a
						write string 2, "entityelement(e).eleprof.explodable: "+str$(entityelement(e).eleprof.explodable)
						read long 1,a : entityelement(e).eleprof.explodedamage=a
						write string 2, "entityelement(e).eleprof.explodedamage: "+str$(entityelement(e).eleprof.explodedamage)
						read long 1,a : entityelement(e).eleprof.phydw4=a
						write string 2, "entityelement(e).eleprof.phydw4: "+str$(entityelement(e).eleprof.phydw4)
						read long 1,a : entityelement(e).eleprof.phydw5=a
						write string 2, "entityelement(e).eleprof.phydw5: "+str$(entityelement(e).eleprof.phydw5)
					endif

if versionnumberload >= 104

//  Version 1.04 - BETA4 extra field
						read long 1,a : entityelement(e).eleprof.phyalways=a
						write string 2, "entityelement(e).eleprof.phyalways: "+str$(entityelement(e).eleprof.phyalways)

					endif

if versionnumberload >= 105
						//  Version 1.05 - BETA8 extra fields
						read long 1,a : entityelement(e).eleprof.spawndelayrandom=a
						write string 2, "entityelement(e).eleprof.spawndelayrandom: "+str$(entityelement(e).eleprof.spawndelayrandom)
						read long 1,a : entityelement(e).eleprof.spawnqtyrandom=a
						write string 2, "entityelement(e).eleprof.spawnqtyrandom: "+str$(entityelement(e).eleprof.spawnqtyrandom)
						read long 1,a : entityelement(e).eleprof.spawnvel=a
						write string 2, "entityelement(e).eleprof.spawnvel: "+str$(entityelement(e).eleprof.spawnvel)
						read long 1,a : entityelement(e).eleprof.spawnvelrandom=a
						write string 2, "entityelement(e).eleprof.spawnvelrandom: "+str$(entityelement(e).eleprof.spawnvelrandom)
						read long 1,a : entityelement(e).eleprof.spawnangle=a
						write string 2, "entityelement(e).eleprof.spawnangle: "+str$(entityelement(e).eleprof.spawnangle)
						read long 1,a : entityelement(e).eleprof.spawnanglerandom=a
						write string 2, "entityelement(e).eleprof.spawnanglerandom: "+str$(entityelement(e).eleprof.spawnanglerandom)
					endif

if versionnumberload >= 106
						//  Version 1.06 - BETA10 extra fields
						read long 1,a : entityelement(e).eleprof.spawnatstart=a
						write string 2, "entityelement(e).eleprof.spawnatstart: "+str$(entityelement(e).eleprof.spawnatstart)
						read long 1,a : entityelement(e).eleprof.spawnlife=a
						write string 2, "entityelement(e).eleprof.spawnlife: "+str$(entityelement(e).eleprof.spawnlife)

endif

					if versionnumberload >= 107
						//  FPSCV104RC8 - forgot to save infinilight index (dynamic lights in final build never worked)
						read long 1,a : entityelement(e).eleprof.light.index=a
						write string 2, "entityelement(e).eleprof.light.index: "+str$(entityelement(e).eleprof.light.index)
					endif

if versionnumberload >= 199
						//  X10 EXTRAS - Ignored in X9
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
					endif

if versionnumberload >= 200
						//  X10 EXTRAS 190707 - Ignored in X9
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
					endif

if versionnumberload >= 217
						//  FPGC - 300710 - save new entity element data
						read long 1,a : entityelement(e).eleprof.particleoverride = a
						write string 2, "entityelement(e).eleprof.particleoverride: "+str$(entityelement(e).eleprof.particleoverride)
						read long 1,a : entityelement(e).eleprof.particle.offsety = a
						write string 2, "entityelement(e).eleprof.particle.offsety: "+str$(entityelement(e).eleprof.particle.offsety)
						read long 1,a : entityelement(e).eleprof.particle.scale = a
						write string 2, "entityelement(e).eleprof.particle.scale: "+str$(entityelement(e).eleprof.particle.scale)
						read long 1,a : entityelement(e).eleprof.particle.randomstartx = a
						write string 2, "entityelement(e).eleprof.particle.randomstartx: "+str$(entityelement(e).eleprof.particle.randomstartx)
						read long 1,a : entityelement(e).eleprof.particle.randomstarty = a
						write string 2, "entityelement(e).eleprof.particle.randomstarty: "+str$(entityelement(e).eleprof.particle.randomstarty)
						read long 1,a : entityelement(e).eleprof.particle.randomstartz = a
						write string 2, "entityelement(e).eleprof.particle.randomstartz: "+str$(entityelement(e).eleprof.particle.randomstartz)
						read long 1,a : entityelement(e).eleprof.particle.linearmotionx = a
						write string 2, "entityelement(e).eleprof.particle.linearmotionx: "+str$(entityelement(e).eleprof.particle.linearmotionx)
						read long 1,a : entityelement(e).eleprof.particle.linearmotiony = a
						write string 2, "entityelement(e).eleprof.particle.linearmotiony: "+str$(entityelement(e).eleprof.particle.linearmotiony)
						read long 1,a : entityelement(e).eleprof.particle.linearmotionz = a
						write string 2, "entityelement(e).eleprof.particle.linearmotionz: "+str$(entityelement(e).eleprof.particle.linearmotionz)
						read long 1,a : entityelement(e).eleprof.particle.randommotionx = a
						write string 2, "entityelement(e).eleprof.particle.randommotionx: "+str$(entityelement(e).eleprof.particle.randommotionx)
						read long 1,a : entityelement(e).eleprof.particle.randommotiony = a
						write string 2, "entityelement(e).eleprof.particle.randommotiony: "+str$(entityelement(e).eleprof.particle.randommotiony)
						read long 1,a : entityelement(e).eleprof.particle.randommotionz = a
						write string 2, "entityelement(e).eleprof.particle.randommotionz: "+str$(entityelement(e).eleprof.particle.randommotionz)
						read long 1,a : entityelement(e).eleprof.particle.mirrormode = a
						write string 2, "entityelement(e).eleprof.particle.mirrormode: "+str$(entityelement(e).eleprof.particle.mirrormode)
						read long 1,a : entityelement(e).eleprof.particle.camerazshift = a
						write string 2, "entityelement(e).eleprof.particle.camerazshift: "+str$(entityelement(e).eleprof.particle.camerazshift)
						read long 1,a : entityelement(e).eleprof.particle.scaleonlyx = a
						write string 2, "entityelement(e).eleprof.particle.scaleonlyx: "+str$(entityelement(e).eleprof.particle.scaleonlyx)
						read long 1,a : entityelement(e).eleprof.particle.lifeincrement = a
						write string 2, "entityelement(e).eleprof.particle.lifeincrement: "+str$(entityelement(e).eleprof.particle.lifeincrement)
						read long 1,a : entityelement(e).eleprof.particle.alphaintensity = a
						write string 2, "entityelement(e).eleprof.particle.alphaintensity: "+str$(entityelement(e).eleprof.particle.alphaintensity)
					endif

if versionnumberload >= 218
						//  V118 - 060810 - knxrb - Decal animation setting (Added animation choice setting).
						read long 1,a : entityelement(e).eleprof.particle.animated = a
						write string 2, "entityelement(e).eleprof.particle.animated: "+str$(entityelement(e).eleprof.particle.animated)
					endif

if versionnumberload >= 301
						//  Reloaded ALPHA 1.0045
						read string 1,a_s : entityelement(e).eleprof.aiinitname_s = a_s
						write string 2, "entityelement(e).eleprof.aiinitname_s: "+entityelement(e).eleprof.aiinitname_s
						read string 1,a_s : entityelement(e).eleprof.aimainname_s = a_s
						write string 2, "entityelement(e).eleprof.aimainname_s: "+entityelement(e).eleprof.aimainname_s
						read string 1,a_s : entityelement(e).eleprof.aidestroyname_s = a_s
						write string 2, "entityelement(e).eleprof.aidestroyname_s: "+entityelement(e).eleprof.aidestroyname_s
						read string 1,a_s : entityelement(e).eleprof.aishootname_s = a_s
						write string 2, "entityelement(e).eleprof.aishootname_s: "+entityelement(e).eleprof.aishootname_s
					endif

if versionnumberload >= 302
						//  Reloaded BETA 1.005
					endif

if versionnumberload >= 303
						//  Reloaded BETA 1.007
						read long 1,a : entityelement(e).eleprof.animspeed = a
						write string 2, "entityelement(e).eleprof.animspeed: "+str$(entityelement(e).eleprof.animspeed)
					endif

if versionnumberload >= 304
						//  Reloaded BETA 1.007-200514
						read float 1,a_f : entityelement(e).eleprof.conerange = a_f
						write string 2, "entityelement(e).eleprof.conerange: "+str$(entityelement(e).eleprof.conerange)
					endif

if versionnumberload >= 305
						//  Reloaded BETA 1.0085
						read float 1,a_f : entityelement(e).scalex = a_f
						write string 2, "entityelement(e).scalex: "+str$(entityelement(e).scalex)
						read float 1,a_f : entityelement(e).scaley = a_f
						write string 2, "entityelement(e).scaley: "+str$(entityelement(e).scaley)
						read float 1,a_f : entityelement(e).scalez = a_f
						write string 2, "entityelement(e).scalez: "+str$(entityelement(e).scalez)
						read long 1,a : entityelement(e).eleprof.range = a
						write string 2, "entityelement(e).eleprof.range: "+str$(entityelement(e).eleprof.range)
						read long 1,a : entityelement(e).eleprof.dropoff = a
						write string 2, "entityelement(e).eleprof.dropoff: "+str$(entityelement(e).eleprof.dropoff)
					endif

if versionnumberload >= 306
						//  GameGuru 1.00.010
						read long 1,a : entityelement(e).eleprof.isviolent = a
						write string 2, "entityelement(e).eleprof.isviolent: "+str$(entityelement(e).eleprof.isviolent)
					endif

if versionnumberload >= 307
						//  GameGuru 1.00.020
						read long 1,a : entityelement(e).eleprof.teamfield = a
						write string 2, "entityelement(e).eleprof.teamfield: "+str$(entityelement(e).eleprof.teamfield)
					endif

if versionnumberload >= 308
						//  GameGuru 1.01.001
						read long 1,a : entityelement(e).eleprof.usespotlighting = a
						write string 2, "entityelement(e).eleprof.usespotlighting: "+str$(entityelement(e).eleprof.usespotlighting)
					endif

if versionnumberload >= 309
						//  GameGuru 1.01.002
						read long 1,a : entityelement(e).eleprof.lodmodifier = a
						write string 2, "entityelement(e).eleprof.lodmodifier: "+str$(entityelement(e).eleprof.lodmodifier)
					endif

if versionnumberload >= 310
						//  GameGuru 1.133
						read long 1,a : entityelement(e).eleprof.isocluder = a
						write string 2, "entityelement(e).eleprof.isocluder: "+str$(entityelement(e).eleprof.isocluder)
						read long 1,a : entityelement(e).eleprof.isocludee = a
						write string 2, "entityelement(e).eleprof.isocludee: "+str$(entityelement(e).eleprof.isocludee)
						read long 1,a : entityelement(e).eleprof.colondeath = a
						write string 2, "entityelement(e).eleprof.colondeath: "+str$(entityelement(e).eleprof.colondeath)
						read long 1,a : entityelement(e).eleprof.parententityindex = a
						write string 2, "entityelement(e).eleprof.parententityindex: "+str$(entityelement(e).eleprof.parententityindex)
						read long 1,a : entityelement(e).eleprof.parentlimbindex = a
						write string 2, "entityelement(e).eleprof.parentlimbindex: "+str$(entityelement(e).eleprof.parentlimbindex)
						read string 1,a_s : entityelement(e).eleprof.soundset2_s = a_s
						write string 2, "entityelement(e).eleprof.soundset2_s: "+entityelement(e).eleprof.soundset2_s
						read string 1,a_s : entityelement(e).eleprof.soundset3_s = a_s
						write string 2, "entityelement(e).eleprof.soundset3_s: "+entityelement(e).eleprof.soundset3_s
						read string 1,a_s : entityelement(e).eleprof.soundset4_s = a_s
						write string 2, "entityelement(e).eleprof.soundset4_s: "+entityelement(e).eleprof.soundset4_s

endif

if versionnumberload >= 311
						//  GameGuru 1.133B
						read float 1,a_f : entityelement(e).eleprof.specularperc = a_f
						write string 2, "entityelement(e).eleprof.specularperc: "+str$(entityelement(e).eleprof.specularperc)
					endif

if versionnumberload >= 312
						//  GameGuru 1.14 EBE
						read long 1,a : entityelement(e).iHasParentIndex = a
						write string 2, "entityelement(e).iHasParentIndex: "+str$(entityelement(e).iHasParentIndex)
					endif

//  fill in the blanks if load older version
					`ttentid=entityelement(e).bankindex;
					`if versionnumberload <103
						//  Version 1.03 - V1 draft physics (-1 means calculate at entobj-loadtime)
						`entityelement(e).eleprof.physics=entityprofile(ttentid).physics;
						`entityelement(e).eleprof.phyweight=entityprofile(ttentid).phyweight;
						`entityelement(e).eleprof.phyfriction=entityprofile(ttentid).phyfriction;
						`entityelement(e).eleprof.phyforcedamage=entityprofile(ttentid).phyforcedamage;
						`entityelement(e).eleprof.rotatethrow=entityprofile(ttentid).rotatethrow;
						`entityelement(e).eleprof.explodable=entityprofile(ttentid).explodable;
						`entityelement(e).eleprof.phydw3=0;
						`entityelement(e).eleprof.phydw4=0;
						`entityelement(e).eleprof.phydw5=0;
					`endif

next e

endif
endif

close file 1
close file 2

end

+ Code Snippet


failedtoload=0
versionnumbersupported = 312

type light_elements
	color as dword
	range as dword
	index as dword
endtype

type trigger_elements
	stylecolor as dword
	waypointzoneindex as dword
endtype

type particle_elements
	offsety as dword
	scale as dword
	randomstartx as dword
	randomstarty as dword
	randomstartz as dword
	linearmotionx as dword
	linearmotiony as dword
	linearmotionz as dword
	randommotionx as dword
	randommotiony as dword
	randommotionz as dword
	mirrormode as dword
	camerazshift as dword
	scaleonlyx as dword
	lifeincrement as dword
	alphaintensity as dword
	animated as dword
endtype

type eleprof_elements
	name_s as string
	aiinit_s as string
	aimain_s as string
	aidestroy_s as string
	isobjective as dword
	usekey_s as string
	ifused_s as string
	ifusednear_s as string
	uniqueelement as dword
	texd_s as string
	texaltd_s as string
	effect_s as string
	transparency as dword
	soundset_s as string
	soundset1_s as string
	spawnmax as dword
	spawndelay as dword
	spawnqty as dword
	hurtfall as dword
	castshadow as dword
	reducetexture as dword
	speed=t.a as dword
	aishoot_s as string
	hasweapon_s as string
	lives as dword
	scale as float
	coneheight as float
	coneangle as float
	strength as dword
	isimmobile as dword
	cantakeweapon as dword
	quantity as dword
	markerindex as dword
	light as light_elements
	trigger as trigger_elements
	basedecal_s as string
	rateoffire as dword
	damage as dword
	accuracy as dword
	reloadqty as dword
	fireiterations as dword
	lifespan as dword
	throwspeed as float
	throwangle as float
	bounceqty as dword
	explodeonhit as dword
	weaponisammo as dword
	spawnupto as dword
	spawnafterdelay as dword
	spawnwhendead as dword
	spare1 as dword
	physics as dword
	phyweight as dword
	phyfriction as dword
	phyforcedamage as dword
	rotatethrow as dword
	explodable as dword
	explodedamage as dword
	phydw4 as dword
	phydw5 as dword
	phyalways as dword
	spawndelayrandom as dword
	spawnqtyrandom as dword
	spawnvel as dword
	spawnvelrandom as dword
	spawnangle as dword
	spawnanglerandom as dword
	spawnatstart as dword
	spawnlife as dword
	particleoverride as dword
	particle as particle_elements
	aiinitname_s as string
	aimainname_s as string
	aidestroyname_s as string
	aishootname_s as string
	animspeed as dword
	conerange as float
	range as dword
	dropoff as dword
	isviolent as dword
	teamfield as dword
	usespotlighting as dword
	lodmodifier as dword
	isocluder as dword
	isocludee as dword
	colondeath as dword
	parententityindex as dword
	parentlimbindex as dword
	soundset2_s as string
	soundset3_s as string
	soundset4_s as string
	specularperc as float
endtype

type spawn_elements
	max as dword
	delay as dword
	qty as dword
endtype

type elements
	maintype as dword
	bankindex as dword
	staticflag as dword
	x	as float
	y	as float
	z	as float
	rx	as float
	ry	as float
	rz	as float
	eleprof as eleprof_elements
	editorfixed as dword
	lives as dword
	spawn as spawn_elements
	scalex as float
	scaley as float
	scalez as float
	iHasParentIndex as dword
endtype

a as dword
a_f as float
a_s as string
dw as dword

global g_entityelementlist
global g_entityelementmax
global g_globalselectedshadermax

`src$="C:\temp\gg_work_out\map.ele"
src$="map.ele"

if file exist("mapele.txt")=1 then delete file "mapele.txt"
open to write 2,"mapele.txt"
open to read 1,src$
read long 1,versionnumberload
write string 2, "Versionnumberload: "+str$(versionnumberload)
read long 1,g_entityelementlist
write string 2, "g_entityelementlist: "+str$(g_entityelementlist)

if versionnumberload <= versionnumbersupported

	if g_entityelementlist>0

		undim entityelement()
		`undim entityshadervar()
		`undim entitydebug_s()
		g_entityelementmax=g_entityelementlist
		dim entityelement(g_entityelementmax) as elements
		`dim entityshadervar(g_entityelementmax,g_globalselectedshadermax)
		`dim entitydebug_s(g_entityelementmax)


				for e= 1 to g_entityelementlist
					`if ( t.game.runasmultiplayer == 1 ) steam_refresh ( );
					//  actual file data
					if versionnumberload >= 101
						//  Version 1.01
						read long 1,a : entityelement(e).maintype = a
						write string 2, "entityelement(e).maintype: "+str$(entityelement(e).maintype)
						read long 1,a : entityelement(e).bankindex = a
						write string 2, "entityelement(e).bankindex: "+str$(entityelement(e).bankindex)
						read long 1,a : entityelement(e).staticflag = a
						write string 2, "entityelement(e).staticflag: "+str$(entityelement(e).staticflag)
						read float 1,a_f : entityelement(e).x=a_f
						write string 2, "entityelement(e).x: "+str$(entityelement(e).x)
						read float 1,a_f : entityelement(e).y=a_f
						write string 2, "entityelement(e).y: "+str$(entityelement(e).y)
						read float 1,a_f : entityelement(e).z=a_f
						write string 2, "entityelement(e).z: "+str$(entityelement(e).z)
						read float 1,a_f : entityelement(e).rx=a_f
						write string 2, "entityelement(e).rx: "+str$(entityelement(e).rx)
						read float 1,a_f : entityelement(e).ry=a_f
						write string 2, "entityelement(e).ry: "+str$(entityelement(e).ry)
						read float 1,a_f : entityelement(e).rz=a_f
						write string 2, "entityelement(e).rz: "+str$(entityelement(e).rz)
						read string 1,a_s : entityelement(e).eleprof.name_s=a_s
						write string 2, "entityelement(e).eleprof.name_s: "+entityelement(e).eleprof.name_s
						read string 1,a_s : entityelement(e).eleprof.aiinit_s=a_s
						write string 2, "entityelement(e).eleprof.aiinit_s: "+entityelement(e).eleprof.aiinit_s
						read string 1,a_s : entityelement(e).eleprof.aimain_s=a_s
						write string 2, "entityelement(e).eleprof.aimain_s: "+entityelement(e).eleprof.aimain_s
						read string 1,a_s : entityelement(e).eleprof.aidestroy_s=a_s
						write string 2, "entityelement(e).eleprof.aidestroy_s: "+entityelement(e).eleprof.aidestroy_s
						read long 1,a : entityelement(e).eleprof.isobjective=a
						write string 2, "entityelement(e).eleprof.isobjective: "+str$(entityelement(e).eleprof.isobjective)
						read string 1,a_s : entityelement(e).eleprof.usekey_s=a_s
						write string 2, "entityelement(e).eleprof.usekey_s: "+entityelement(e).eleprof.usekey_s
						read string 1,a_s : entityelement(e).eleprof.ifused_s=a_s
						write string 2, "entityelement(e).eleprof.ifused_s: "+entityelement(e).eleprof.ifused_s
						read string 1,a_s : entityelement(e).eleprof.ifusednear_s=a_s
						write string 2, "entityelement(e).eleprof.ifusednear_s: "+entityelement(e).eleprof.ifusednear_s
						read long 1,a : entityelement(e).eleprof.uniqueelement=a
						write string 2, "entityelement(e).eleprof.uniqueelement: "+str$(entityelement(e).eleprof.uniqueelement)
						read string 1,a_s : entityelement(e).eleprof.texd_s=a_s
						write string 2, "entityelement(e).eleprof.texd_s: "+entityelement(e).eleprof.texd_s
						read string 1,a_s : entityelement(e).eleprof.texaltd_s=a_s
						write string 2, "entityelement(e).eleprof.texaltd_s: "+entityelement(e).eleprof.texaltd_s
						read string 1,a_s : entityelement(e).eleprof.effect_s=a_s
						write string 2, "entityelement(e).eleprof.effect_s: "+entityelement(e).eleprof.effect_s
						read long 1,a : entityelement(e).eleprof.transparency=a
						write string 2, "entityelement(e).eleprof.transparency: "+str$(entityelement(e).eleprof.transparency)
						read long 1,a : entityelement(e).editorfixed=a
						write string 2, "entityelement(e).editorfixed: "+str$(entityelement(e).editorfixed)
						read string 1,a_s : entityelement(e).eleprof.soundset_s=a_s
						write string 2, "entityelement(e).eleprof.soundset_s: "+entityelement(e).eleprof.soundset_s
						read string 1,a_s : entityelement(e).eleprof.soundset1_s=a_s
						write string 2, "entityelement(e).eleprof.soundset1_s: "+entityelement(e).eleprof.soundset1_s
						read long 1,a : entityelement(e).eleprof.spawnmax=a
						write string 2, "entityelement(e).eleprof.spawnmax: "+str$(entityelement(e).eleprof.spawnmax)
						read long 1,a : entityelement(e).eleprof.spawndelay=a
						write string 2, "entityelement(e).eleprof.spawndelay: "+str$(entityelement(e).eleprof.spawndelay)
						read long 1,a : entityelement(e).eleprof.spawnqty=a
						write string 2, "entityelement(e).eleprof.spawnqty: "+str$(entityelement(e).eleprof.spawnqty)
						read long 1,a : entityelement(e).eleprof.hurtfall=a
						write string 2, "entityelement(e).eleprof.hurtfall: "+str$(entityelement(e).eleprof.hurtfall)
						read long 1,a : entityelement(e).eleprof.castshadow=a
						write string 2, "entityelement(e).eleprof.castshadow: "+str$(entityelement(e).eleprof.castshadow)
						read long 1,a : entityelement(e).eleprof.reducetexture=a
						write string 2, "entityelement(e).eleprof.reducetexture: "+str$(entityelement(e).eleprof.reducetexture)
						read long 1,a : entityelement(e).eleprof.speed=a
						write string 2, "entityelement(e).eleprof.speed: "+str$(entityelement(e).eleprof.speed)
						read string 1,a_s : entityelement(e).eleprof.aishoot_s=a_s
						write string 2, "entityelement(e).eleprof.aishoot_s: "+entityelement(e).eleprof.aishoot_s
						read string 1,a_s : entityelement(e).eleprof.hasweapon_s=a_s
						write string 2, "entityelement(e).eleprof.hasweapon_s: "+entityelement(e).eleprof.hasweapon_s
						read long 1,a : entityelement(e).eleprof.lives=a
						write string 2, "entityelement(e).eleprof.lives: "+str$(entityelement(e).eleprof.lives)
						read long 1,a : entityelement(e).spawn.max=a
						write string 2, "entityelement(e).spawn.max: "+str$(entityelement(e).spawn.max)
						read long 1,a : entityelement(e).spawn.delay=a
						write string 2, "entityelement(e).spawn.delay: "+str$(entityelement(e).spawn.delay)
						read long 1,a : entityelement(e).spawn.qty=a
						write string 2, "entityelement(e).spawn.qty: "+str$(entityelement(e).spawn.qty)
						read float 1,a_f : entityelement(e).eleprof.scale=a_f
						write string 2, "entityelement(e).eleprof.scale: "+str$(entityelement(e).eleprof.scale)
						read float 1,a_f : entityelement(e).eleprof.coneheight=a_f
						write string 2, "entityelement(e).eleprof.coneheight: "+str$(entityelement(e).eleprof.coneheight)
						read float 1,a_f : entityelement(e).eleprof.coneangle=a_f
						write string 2, "entityelement(e).eleprof.coneangle: "+str$(entityelement(e).eleprof.coneangle)
						read long 1,a : entityelement(e).eleprof.strength=a
						write string 2, "entityelement(e).eleprof.strength: "+str$(entityelement(e).eleprof.strength)
						read long 1,a : entityelement(e).eleprof.isimmobile=a
						write string 2, "entityelement(e).eleprof.isimmobile: "+str$(entityelement(e).eleprof.isimmobile)
						read long 1,a : entityelement(e).eleprof.cantakeweapon=a
						write string 2, "entityelement(e).eleprof.cantakeweapon: "+str$(entityelement(e).eleprof.cantakeweapon)
						read long 1,a : entityelement(e).eleprof.quantity=a
						write string 2, "entityelement(e).eleprof.quantity: "+str$(entityelement(e).eleprof.quantity)
						read long 1,a : entityelement(e).eleprof.markerindex=a
						write string 2, "entityelement(e).eleprof.markerindex: "+str$(entityelement(e).eleprof.markerindex)
						read long 1,a : dw=a : dw=dw+0xFF000000 : entityelement(e).eleprof.light.color=dw
						write string 2, "entityelement(e).eleprof.light.color: "+str$(entityelement(e).eleprof.light.color)
						read long 1,a : entityelement(e).eleprof.light.range=a
						write string 2, "entityelement(e).eleprof.light.range: "+str$(entityelement(e).eleprof.light.range)
						read long 1,a : entityelement(e).eleprof.trigger.stylecolor=a
						write string 2, "entityelement(e).eleprof.trigger.stylecolor: "+str$(entityelement(e).eleprof.trigger.stylecolor)
						read long 1,a : entityelement(e).eleprof.trigger.waypointzoneindex=a
						write string 2, "entityelement(e).eleprof.trigger.waypointzoneindex: "+str$(entityelement(e).eleprof.trigger.waypointzoneindex)
						read string 1,a_s : entityelement(e).eleprof.basedecal_s=a_s
						write string 2, "entityelement(e).eleprof.basedecal_s: "+entityelement(e).eleprof.basedecal_s
					endif

					if versionnumberload >= 102
						//  Version 1.02
						read long 1,a : entityelement(e).eleprof.rateoffire=a
						write string 2, "entityelement(e).eleprof.rateoffire: "+str$(entityelement(e).eleprof.rateoffire)
						read long 1,a : entityelement(e).eleprof.damage=a
						write string 2, "entityelement(e).eleprof.damage: "+str$(entityelement(e).eleprof.damage)
						read long 1,a : entityelement(e).eleprof.accuracy=a
						write string 2, "entityelement(e).eleprof.accuracy: "+str$(entityelement(e).eleprof.accuracy)
						read long 1,a : entityelement(e).eleprof.reloadqty=a
						write string 2, "entityelement(e).eleprof.reloadqty: "+str$(entityelement(e).eleprof.reloadqty)
						read long 1,a : entityelement(e).eleprof.fireiterations=a
						write string 2, "entityelement(e).eleprof.fireiterations: "+str$(entityelement(e).eleprof.fireiterations)
						read long 1,a : entityelement(e).eleprof.lifespan=a
						write string 2, "entityelement(e).eleprof.lifespan: "+str$(entityelement(e).eleprof.lifespan)
						read float 1,a_f : entityelement(e).eleprof.throwspeed=a_f
						write string 2, "entityelement(e).eleprof.throwspeed: "+str$(entityelement(e).eleprof.throwspeed)
						read float 1,a_f : entityelement(e).eleprof.throwangle=a_f
						write string 2, "entityelement(e).eleprof.throwangle: "+str$(entityelement(e).eleprof.throwangle)
						read long 1,a : entityelement(e).eleprof.bounceqty=a
						write string 2, "entityelement(e).eleprof.bounceqty: "+str$(entityelement(e).eleprof.bounceqty)
						read long 1,a : entityelement(e).eleprof.explodeonhit=a
						write string 2, "entityelement(e).eleprof.explodeonhit: "+str$(entityelement(e).eleprof.explodeonhit)
						read long 1,a : entityelement(e).eleprof.weaponisammo=a
						write string 2, "entityelement(e).eleprof.weaponisammo: "+str$(entityelement(e).eleprof.weaponisammo)
						read long 1,a : entityelement(e).eleprof.spawnupto=a
						write string 2, "entityelement(e).eleprof.spawnupto: "+str$(entityelement(e).eleprof.spawnupto)
						read long 1,a : entityelement(e).eleprof.spawnafterdelay=a
						write string 2, "entityelement(e).eleprof.spawnafterdelay: "+str$(entityelement(e).eleprof.spawnafterdelay)
						read long 1,a : entityelement(e).eleprof.spawnwhendead=a
						write string 2, "entityelement(e).eleprof.spawnwhendead: "+str$(entityelement(e).eleprof.spawnwhendead)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
						read long 1,a : entityelement(e).eleprof.spare1=a
						write string 2, "entityelement(e).eleprof.spare1: "+str$(entityelement(e).eleprof.spare1)
					endif

					if versionnumberload >= 103
						//  Version 1.03

						read long 1,a : entityelement(e).eleprof.physics=a
						write string 2, "entityelement(e).eleprof.physics: "+str$(entityelement(e).eleprof.physics)
						read long 1,a : entityelement(e).eleprof.phyweight=a
						write string 2, "entityelement(e).eleprof.phyweight: "+str$(entityelement(e).eleprof.phyweight)
						read long 1,a : entityelement(e).eleprof.phyfriction=a
						write string 2, "entityelement(e).eleprof.phyfriction: "+str$(entityelement(e).eleprof.phyfriction)
						read long 1,a : entityelement(e).eleprof.phyforcedamage=a
						write string 2, "entityelement(e).eleprof.phyforcedamage: "+str$(entityelement(e).eleprof.phyforcedamage)
						read long 1,a : entityelement(e).eleprof.rotatethrow=a
						write string 2, "entityelement(e).eleprof.rotatethrow: "+str$(entityelement(e).eleprof.rotatethrow)
						read long 1,a : entityelement(e).eleprof.explodable=a
						write string 2, "entityelement(e).eleprof.explodable: "+str$(entityelement(e).eleprof.explodable)
						read long 1,a : entityelement(e).eleprof.explodedamage=a
						write string 2, "entityelement(e).eleprof.explodedamage: "+str$(entityelement(e).eleprof.explodedamage)
						read long 1,a : entityelement(e).eleprof.phydw4=a
						write string 2, "entityelement(e).eleprof.phydw4: "+str$(entityelement(e).eleprof.phydw4)
						read long 1,a : entityelement(e).eleprof.phydw5=a
						write string 2, "entityelement(e).eleprof.phydw5: "+str$(entityelement(e).eleprof.phydw5)
					endif

					if versionnumberload >= 104

						//  Version 1.04 - BETA4 extra field
						read long 1,a : entityelement(e).eleprof.phyalways=a
						write string 2, "entityelement(e).eleprof.phyalways: "+str$(entityelement(e).eleprof.phyalways)

					endif

					if versionnumberload >= 105
						//  Version 1.05 - BETA8 extra fields
						read long 1,a : entityelement(e).eleprof.spawndelayrandom=a
						write string 2, "entityelement(e).eleprof.spawndelayrandom: "+str$(entityelement(e).eleprof.spawndelayrandom)
						read long 1,a : entityelement(e).eleprof.spawnqtyrandom=a
						write string 2, "entityelement(e).eleprof.spawnqtyrandom: "+str$(entityelement(e).eleprof.spawnqtyrandom)
						read long 1,a : entityelement(e).eleprof.spawnvel=a
						write string 2, "entityelement(e).eleprof.spawnvel: "+str$(entityelement(e).eleprof.spawnvel)
						read long 1,a : entityelement(e).eleprof.spawnvelrandom=a
						write string 2, "entityelement(e).eleprof.spawnvelrandom: "+str$(entityelement(e).eleprof.spawnvelrandom)
						read long 1,a : entityelement(e).eleprof.spawnangle=a
						write string 2, "entityelement(e).eleprof.spawnangle: "+str$(entityelement(e).eleprof.spawnangle)
						read long 1,a : entityelement(e).eleprof.spawnanglerandom=a
						write string 2, "entityelement(e).eleprof.spawnanglerandom: "+str$(entityelement(e).eleprof.spawnanglerandom)
					endif

					if versionnumberload >= 106
						//  Version 1.06 - BETA10 extra fields
						read long 1,a : entityelement(e).eleprof.spawnatstart=a
						write string 2, "entityelement(e).eleprof.spawnatstart: "+str$(entityelement(e).eleprof.spawnatstart)
						read long 1,a : entityelement(e).eleprof.spawnlife=a
						write string 2, "entityelement(e).eleprof.spawnlife: "+str$(entityelement(e).eleprof.spawnlife)

					endif

					if versionnumberload >= 107
						//  FPSCV104RC8 - forgot to save infinilight index (dynamic lights in final build never worked)
						read long 1,a : entityelement(e).eleprof.light.index=a
						write string 2, "entityelement(e).eleprof.light.index: "+str$(entityelement(e).eleprof.light.index)
					endif

					if versionnumberload >= 199
						//  X10 EXTRAS - Ignored in X9
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
					endif

					if versionnumberload >= 200
						//  X10 EXTRAS 190707 - Ignored in X9
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
						read long 1,a
						write string 2, "X10 elements: ignored in X9: "+str$(a)
					endif

					if versionnumberload >= 217
						//  FPGC - 300710 - save new entity element data
						read long 1,a : entityelement(e).eleprof.particleoverride = a
						write string 2, "entityelement(e).eleprof.particleoverride: "+str$(entityelement(e).eleprof.particleoverride)
						read long 1,a : entityelement(e).eleprof.particle.offsety = a
						write string 2, "entityelement(e).eleprof.particle.offsety: "+str$(entityelement(e).eleprof.particle.offsety)
						read long 1,a : entityelement(e).eleprof.particle.scale = a
						write string 2, "entityelement(e).eleprof.particle.scale: "+str$(entityelement(e).eleprof.particle.scale)
						read long 1,a : entityelement(e).eleprof.particle.randomstartx = a
						write string 2, "entityelement(e).eleprof.particle.randomstartx: "+str$(entityelement(e).eleprof.particle.randomstartx)
						read long 1,a : entityelement(e).eleprof.particle.randomstarty = a
						write string 2, "entityelement(e).eleprof.particle.randomstarty: "+str$(entityelement(e).eleprof.particle.randomstarty)
						read long 1,a : entityelement(e).eleprof.particle.randomstartz = a
						write string 2, "entityelement(e).eleprof.particle.randomstartz: "+str$(entityelement(e).eleprof.particle.randomstartz)
						read long 1,a : entityelement(e).eleprof.particle.linearmotionx = a
						write string 2, "entityelement(e).eleprof.particle.linearmotionx: "+str$(entityelement(e).eleprof.particle.linearmotionx)
						read long 1,a : entityelement(e).eleprof.particle.linearmotiony = a
						write string 2, "entityelement(e).eleprof.particle.linearmotiony: "+str$(entityelement(e).eleprof.particle.linearmotiony)
						read long 1,a : entityelement(e).eleprof.particle.linearmotionz = a
						write string 2, "entityelement(e).eleprof.particle.linearmotionz: "+str$(entityelement(e).eleprof.particle.linearmotionz)
						read long 1,a : entityelement(e).eleprof.particle.randommotionx = a
						write string 2, "entityelement(e).eleprof.particle.randommotionx: "+str$(entityelement(e).eleprof.particle.randommotionx)
						read long 1,a : entityelement(e).eleprof.particle.randommotiony = a
						write string 2, "entityelement(e).eleprof.particle.randommotiony: "+str$(entityelement(e).eleprof.particle.randommotiony)
						read long 1,a : entityelement(e).eleprof.particle.randommotionz = a
						write string 2, "entityelement(e).eleprof.particle.randommotionz: "+str$(entityelement(e).eleprof.particle.randommotionz)
						read long 1,a : entityelement(e).eleprof.particle.mirrormode = a
						write string 2, "entityelement(e).eleprof.particle.mirrormode: "+str$(entityelement(e).eleprof.particle.mirrormode)
						read long 1,a : entityelement(e).eleprof.particle.camerazshift = a
						write string 2, "entityelement(e).eleprof.particle.camerazshift: "+str$(entityelement(e).eleprof.particle.camerazshift)
						read long 1,a : entityelement(e).eleprof.particle.scaleonlyx = a
						write string 2, "entityelement(e).eleprof.particle.scaleonlyx: "+str$(entityelement(e).eleprof.particle.scaleonlyx)
						read long 1,a : entityelement(e).eleprof.particle.lifeincrement = a
						write string 2, "entityelement(e).eleprof.particle.lifeincrement: "+str$(entityelement(e).eleprof.particle.lifeincrement)
						read long 1,a : entityelement(e).eleprof.particle.alphaintensity = a
						write string 2, "entityelement(e).eleprof.particle.alphaintensity: "+str$(entityelement(e).eleprof.particle.alphaintensity)
					endif

					if versionnumberload >= 218
						//  V118 - 060810 - knxrb - Decal animation setting (Added animation choice setting).
						read long 1,a : entityelement(e).eleprof.particle.animated = a
						write string 2, "entityelement(e).eleprof.particle.animated: "+str$(entityelement(e).eleprof.particle.animated)
					endif

					if versionnumberload >= 301
						//  Reloaded ALPHA 1.0045
						read string 1,a_s : entityelement(e).eleprof.aiinitname_s = a_s
						write string 2, "entityelement(e).eleprof.aiinitname_s: "+entityelement(e).eleprof.aiinitname_s
						read string 1,a_s : entityelement(e).eleprof.aimainname_s = a_s
						write string 2, "entityelement(e).eleprof.aimainname_s: "+entityelement(e).eleprof.aimainname_s
						read string 1,a_s : entityelement(e).eleprof.aidestroyname_s = a_s
						write string 2, "entityelement(e).eleprof.aidestroyname_s: "+entityelement(e).eleprof.aidestroyname_s
						read string 1,a_s : entityelement(e).eleprof.aishootname_s = a_s
						write string 2, "entityelement(e).eleprof.aishootname_s: "+entityelement(e).eleprof.aishootname_s
					endif

					if versionnumberload >= 302
						//  Reloaded BETA 1.005
					endif

					if versionnumberload >= 303
						//  Reloaded BETA 1.007
						read long 1,a : entityelement(e).eleprof.animspeed = a
						write string 2, "entityelement(e).eleprof.animspeed: "+str$(entityelement(e).eleprof.animspeed)
					endif

					if versionnumberload >= 304
						//  Reloaded BETA 1.007-200514
						read float 1,a_f : entityelement(e).eleprof.conerange = a_f
						write string 2, "entityelement(e).eleprof.conerange: "+str$(entityelement(e).eleprof.conerange)
					endif

					if versionnumberload >= 305
						//  Reloaded BETA 1.0085
						read float 1,a_f : entityelement(e).scalex = a_f
						write string 2, "entityelement(e).scalex: "+str$(entityelement(e).scalex)
						read float 1,a_f : entityelement(e).scaley = a_f
						write string 2, "entityelement(e).scaley: "+str$(entityelement(e).scaley)
						read float 1,a_f : entityelement(e).scalez = a_f
						write string 2, "entityelement(e).scalez: "+str$(entityelement(e).scalez)
						read long 1,a : entityelement(e).eleprof.range = a
						write string 2, "entityelement(e).eleprof.range: "+str$(entityelement(e).eleprof.range)
						read long 1,a : entityelement(e).eleprof.dropoff = a
						write string 2, "entityelement(e).eleprof.dropoff: "+str$(entityelement(e).eleprof.dropoff)
					endif

					if versionnumberload >= 306
						//  GameGuru 1.00.010
						read long 1,a : entityelement(e).eleprof.isviolent = a
						write string 2, "entityelement(e).eleprof.isviolent: "+str$(entityelement(e).eleprof.isviolent)
					endif

					if versionnumberload >= 307
						//  GameGuru 1.00.020
						read long 1,a : entityelement(e).eleprof.teamfield = a
						write string 2, "entityelement(e).eleprof.teamfield: "+str$(entityelement(e).eleprof.teamfield)
					endif

					if versionnumberload >= 308
						//  GameGuru 1.01.001
						read long 1,a : entityelement(e).eleprof.usespotlighting = a
						write string 2, "entityelement(e).eleprof.usespotlighting: "+str$(entityelement(e).eleprof.usespotlighting)
					endif

					if versionnumberload >= 309
						//  GameGuru 1.01.002
						read long 1,a : entityelement(e).eleprof.lodmodifier = a
						write string 2, "entityelement(e).eleprof.lodmodifier: "+str$(entityelement(e).eleprof.lodmodifier)
					endif

					if versionnumberload >= 310
						//  GameGuru 1.133
						read long 1,a : entityelement(e).eleprof.isocluder = a
						write string 2, "entityelement(e).eleprof.isocluder: "+str$(entityelement(e).eleprof.isocluder)
						read long 1,a : entityelement(e).eleprof.isocludee = a
						write string 2, "entityelement(e).eleprof.isocludee: "+str$(entityelement(e).eleprof.isocludee)
						read long 1,a : entityelement(e).eleprof.colondeath = a
						write string 2, "entityelement(e).eleprof.colondeath: "+str$(entityelement(e).eleprof.colondeath)
						read long 1,a : entityelement(e).eleprof.parententityindex = a
						write string 2, "entityelement(e).eleprof.parententityindex: "+str$(entityelement(e).eleprof.parententityindex)
						read long 1,a : entityelement(e).eleprof.parentlimbindex = a
						write string 2, "entityelement(e).eleprof.parentlimbindex: "+str$(entityelement(e).eleprof.parentlimbindex)
						read string 1,a_s : entityelement(e).eleprof.soundset2_s = a_s
						write string 2, "entityelement(e).eleprof.soundset2_s: "+entityelement(e).eleprof.soundset2_s
						read string 1,a_s : entityelement(e).eleprof.soundset3_s = a_s
						write string 2, "entityelement(e).eleprof.soundset3_s: "+entityelement(e).eleprof.soundset3_s
						read string 1,a_s : entityelement(e).eleprof.soundset4_s = a_s
						write string 2, "entityelement(e).eleprof.soundset4_s: "+entityelement(e).eleprof.soundset4_s

					endif

					if versionnumberload >= 311
						//  GameGuru 1.133B
						read float 1,a_f : entityelement(e).eleprof.specularperc = a_f
						write string 2, "entityelement(e).eleprof.specularperc: "+str$(entityelement(e).eleprof.specularperc)
					endif

					if versionnumberload >= 312
						//  GameGuru 1.14 EBE
						read long 1,a : entityelement(e).iHasParentIndex = a
						write string 2, "entityelement(e).iHasParentIndex: "+str$(entityelement(e).iHasParentIndex)
					endif

					//  fill in the blanks if load older version
					`ttentid=entityelement(e).bankindex;
					`if versionnumberload <103
						//  Version 1.03 - V1 draft physics (-1 means calculate at entobj-loadtime)
						`entityelement(e).eleprof.physics=entityprofile(ttentid).physics;
						`entityelement(e).eleprof.phyweight=entityprofile(ttentid).phyweight;
						`entityelement(e).eleprof.phyfriction=entityprofile(ttentid).phyfriction;
						`entityelement(e).eleprof.phyforcedamage=entityprofile(ttentid).phyforcedamage;
						`entityelement(e).eleprof.rotatethrow=entityprofile(ttentid).rotatethrow;
						`entityelement(e).eleprof.explodable=entityprofile(ttentid).explodable;
						`entityelement(e).eleprof.phydw3=0;
						`entityelement(e).eleprof.phydw4=0;
						`entityelement(e).eleprof.phydw5=0;
					`endif


				next e







	endif
endif

close file 1
close file 2

end

you should see something like this in the output file "mapele.txt":

Versionnumberload: 312
g_entityelementlist: 2
entityelement(e).maintype: 1
entityelement(e).bankindex: 1
entityelement(e).staticflag: 1
entityelement(e).x: 25221.9824219
entityelement(e).y: 600
entityelement(e).z: 25702.9960938
entityelement(e).rx: 0
entityelement(e).ry: 0
entityelement(e).rz: 0
entityelement(e).eleprof.name_s: City Wall straight
entityelement(e).eleprof.aiinit_s: appear.lua
entityelement(e).eleprof.aimain_s: door.lua
entityelement(e).eleprof.aidestroy_s: disappear.lua
entityelement(e).eleprof.isobjective: 1
entityelement(e).eleprof.usekey_s:
entityelement(e).eleprof.ifused_s:
entityelement(e).eleprof.ifusednear_s:
entityelement(e).eleprof.uniqueelement: 0
entityelement(e).eleprof.texd_s: city_wall_tower_color.dds
entityelement(e).eleprof.texaltd_s:
entityelement(e).eleprof.effect_s: effectbank\reloaded\apbr_basic.fx
entityelement(e).eleprof.transparency: 0
entityelement(e).editorfixed: 0
entityelement(e).eleprof.soundset_s:
entityelement(e).eleprof.soundset1_s:
entityelement(e).eleprof.spawnmax: 0
entityelement(e).eleprof.spawndelay: 0
entityelement(e).eleprof.spawnqty: 0
entityelement(e).eleprof.hurtfall: 100
entityelement(e).eleprof.castshadow: 1
entityelement(e).eleprof.reducetexture: 0
entityelement(e).eleprof.speed: 100
entityelement(e).eleprof.aishoot_s:
entityelement(e).eleprof.hasweapon_s:
entityelement(e).eleprof.lives: 1
entityelement(e).spawn.max: 0
entityelement(e).spawn.delay: 0
entityelement(e).spawn.qty: 0
entityelement(e).eleprof.scale: 100
entityelement(e).eleprof.coneheight: 0
entityelement(e).eleprof.coneangle: 0
entityelement(e).eleprof.strength: 0
entityelement(e).eleprof.isimmobile: 1
entityelement(e).eleprof.cantakeweapon: 0
entityelement(e).eleprof.quantity: 4294967295
entityelement(e).eleprof.markerindex: 0
entityelement(e).eleprof.light.color: 4278190080
entityelement(e).eleprof.light.range: 0
entityelement(e).eleprof.trigger.stylecolor: 0
entityelement(e).eleprof.trigger.waypointzoneindex: 0
entityelement(e).eleprof.basedecal_s:
entityelement(e).eleprof.rateoffire: 85
entityelement(e).eleprof.damage: 0
entityelement(e).eleprof.accuracy: 0
entityelement(e).eleprof.reloadqty: 0
entityelement(e).eleprof.fireiterations: 0
entityelement(e).eleprof.lifespan: 0
entityelement(e).eleprof.throwspeed: 0
entityelement(e).eleprof.throwangle: 0
entityelement(e).eleprof.bounceqty: 0
entityelement(e).eleprof.explodeonhit: 0
entityelement(e).eleprof.weaponisammo: 0
entityelement(e).eleprof.spawnupto: 0
entityelement(e).eleprof.spawnafterdelay: 0
entityelement(e).eleprof.spawnwhendead: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.physics: 1
entityelement(e).eleprof.phyweight: 100
entityelement(e).eleprof.phyfriction: 100
entityelement(e).eleprof.phyforcedamage: 100
entityelement(e).eleprof.rotatethrow: 1
entityelement(e).eleprof.explodable: 0
entityelement(e).eleprof.explodedamage: 100
entityelement(e).eleprof.phydw4: 0
entityelement(e).eleprof.phydw5: 0
entityelement(e).eleprof.phyalways: 0
entityelement(e).eleprof.spawndelayrandom: 0
entityelement(e).eleprof.spawnqtyrandom: 0
entityelement(e).eleprof.spawnvel: 0
entityelement(e).eleprof.spawnvelrandom: 0
entityelement(e).eleprof.spawnangle: 0
entityelement(e).eleprof.spawnanglerandom: 0
entityelement(e).eleprof.spawnatstart: 1
entityelement(e).eleprof.spawnlife: 0
entityelement(e).eleprof.light.index: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
entityelement(e).eleprof.particleoverride: 1
entityelement(e).eleprof.particle.offsety: 0
entityelement(e).eleprof.particle.scale: 0
entityelement(e).eleprof.particle.randomstartx: 0
entityelement(e).eleprof.particle.randomstarty: 0
entityelement(e).eleprof.particle.randomstartz: 0
entityelement(e).eleprof.particle.linearmotionx: 0
entityelement(e).eleprof.particle.linearmotiony: 0
entityelement(e).eleprof.particle.linearmotionz: 0
entityelement(e).eleprof.particle.randommotionx: 0
entityelement(e).eleprof.particle.randommotiony: 0
entityelement(e).eleprof.particle.randommotionz: 0
entityelement(e).eleprof.particle.mirrormode: 0
entityelement(e).eleprof.particle.camerazshift: 0
entityelement(e).eleprof.particle.scaleonlyx: 0
entityelement(e).eleprof.particle.lifeincrement: 0
entityelement(e).eleprof.particle.alphaintensity: 0
entityelement(e).eleprof.particle.animated: 0
entityelement(e).eleprof.aiinitname_s:
entityelement(e).eleprof.aimainname_s:
entityelement(e).eleprof.aidestroyname_s:
entityelement(e).eleprof.aishootname_s:
entityelement(e).eleprof.animspeed: 100
entityelement(e).eleprof.conerange: 0
entityelement(e).scalex: 0
entityelement(e).scaley: 0
entityelement(e).scalez: 0
entityelement(e).eleprof.range: 0
entityelement(e).eleprof.dropoff: 0
entityelement(e).eleprof.isviolent: 1
entityelement(e).eleprof.teamfield: 0
entityelement(e).eleprof.usespotlighting: 0
entityelement(e).eleprof.lodmodifier: 0
entityelement(e).eleprof.isocluder: 1
entityelement(e).eleprof.isocludee: 1
entityelement(e).eleprof.colondeath: 1
entityelement(e).eleprof.parententityindex: 0
entityelement(e).eleprof.parentlimbindex: 0
entityelement(e).eleprof.soundset2_s:
entityelement(e).eleprof.soundset3_s:
entityelement(e).eleprof.soundset4_s:
entityelement(e).eleprof.specularperc: 100
entityelement(e).iHasParentIndex: 0
entityelement(e).maintype: 1
entityelement(e).bankindex: 2
entityelement(e).staticflag: 0
entityelement(e).x: 25135.5390625
entityelement(e).y: 600
entityelement(e).z: 25477.7734375
entityelement(e).rx: 0
entityelement(e).ry: 0
entityelement(e).rz: 0
entityelement(e).eleprof.name_s: Wizard
entityelement(e).eleprof.aiinit_s:
entityelement(e).eleprof.aimain_s: ai_neutral.lua
entityelement(e).eleprof.aidestroy_s:
entityelement(e).eleprof.isobjective: 0
entityelement(e).eleprof.usekey_s:
entityelement(e).eleprof.ifused_s:
entityelement(e).eleprof.ifusednear_s:
entityelement(e).eleprof.uniqueelement: 0
entityelement(e).eleprof.texd_s: wizard_D.dds
entityelement(e).eleprof.texaltd_s:
entityelement(e).eleprof.effect_s: effectbank\reloaded\character_basic.fx
entityelement(e).eleprof.transparency: 0
entityelement(e).editorfixed: 0
entityelement(e).eleprof.soundset_s: Male
entityelement(e).eleprof.soundset1_s:
entityelement(e).eleprof.spawnmax: 0
entityelement(e).eleprof.spawndelay: 0
entityelement(e).eleprof.spawnqty: 0
entityelement(e).eleprof.hurtfall: 100
entityelement(e).eleprof.castshadow: 0
entityelement(e).eleprof.reducetexture: 0
entityelement(e).eleprof.speed: 100
entityelement(e).eleprof.aishoot_s:
entityelement(e).eleprof.hasweapon_s: fantasy\staff
entityelement(e).eleprof.lives: 1
entityelement(e).spawn.max: 0
entityelement(e).spawn.delay: 0
entityelement(e).spawn.qty: 0
entityelement(e).eleprof.scale: 100
entityelement(e).eleprof.coneheight: 0
entityelement(e).eleprof.coneangle: 0
entityelement(e).eleprof.strength: 100
entityelement(e).eleprof.isimmobile: 0
entityelement(e).eleprof.cantakeweapon: 0
entityelement(e).eleprof.quantity: 0
entityelement(e).eleprof.markerindex: 0
entityelement(e).eleprof.light.color: 4278190080
entityelement(e).eleprof.light.range: 0
entityelement(e).eleprof.trigger.stylecolor: 0
entityelement(e).eleprof.trigger.waypointzoneindex: 0
entityelement(e).eleprof.basedecal_s:
entityelement(e).eleprof.rateoffire: 100
entityelement(e).eleprof.damage: 0
entityelement(e).eleprof.accuracy: 0
entityelement(e).eleprof.reloadqty: 0
entityelement(e).eleprof.fireiterations: 0
entityelement(e).eleprof.lifespan: 0
entityelement(e).eleprof.throwspeed: 0
entityelement(e).eleprof.throwangle: 0
entityelement(e).eleprof.bounceqty: 0
entityelement(e).eleprof.explodeonhit: 0
entityelement(e).eleprof.weaponisammo: 0
entityelement(e).eleprof.spawnupto: 0
entityelement(e).eleprof.spawnafterdelay: 0
entityelement(e).eleprof.spawnwhendead: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.physics: 1
entityelement(e).eleprof.phyweight: 100
entityelement(e).eleprof.phyfriction: 100
entityelement(e).eleprof.phyforcedamage: 100
entityelement(e).eleprof.rotatethrow: 1
entityelement(e).eleprof.explodable: 0
entityelement(e).eleprof.explodedamage: 100
entityelement(e).eleprof.phydw4: 0
entityelement(e).eleprof.phydw5: 0
entityelement(e).eleprof.phyalways: 0
entityelement(e).eleprof.spawndelayrandom: 0
entityelement(e).eleprof.spawnqtyrandom: 0
entityelement(e).eleprof.spawnvel: 0
entityelement(e).eleprof.spawnvelrandom: 0
entityelement(e).eleprof.spawnangle: 0
entityelement(e).eleprof.spawnanglerandom: 0
entityelement(e).eleprof.spawnatstart: 1
entityelement(e).eleprof.spawnlife: 0
entityelement(e).eleprof.light.index: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
entityelement(e).eleprof.particleoverride: 1
entityelement(e).eleprof.particle.offsety: 0
entityelement(e).eleprof.particle.scale: 0
entityelement(e).eleprof.particle.randomstartx: 0
entityelement(e).eleprof.particle.randomstarty: 0
entityelement(e).eleprof.particle.randomstartz: 0
entityelement(e).eleprof.particle.linearmotionx: 0
entityelement(e).eleprof.particle.linearmotiony: 0
entityelement(e).eleprof.particle.linearmotionz: 0
entityelement(e).eleprof.particle.randommotionx: 0
entityelement(e).eleprof.particle.randommotiony: 0
entityelement(e).eleprof.particle.randommotionz: 0
entityelement(e).eleprof.particle.mirrormode: 0
entityelement(e).eleprof.particle.camerazshift: 0
entityelement(e).eleprof.particle.scaleonlyx: 0
entityelement(e).eleprof.particle.lifeincrement: 0
entityelement(e).eleprof.particle.alphaintensity: 0
entityelement(e).eleprof.particle.animated: 0
entityelement(e).eleprof.aiinitname_s:
entityelement(e).eleprof.aimainname_s:
entityelement(e).eleprof.aidestroyname_s:
entityelement(e).eleprof.aishootname_s:
entityelement(e).eleprof.animspeed: 100
entityelement(e).eleprof.conerange: 0
entityelement(e).scalex: 0
entityelement(e).scaley: 0
entityelement(e).scalez: 0
entityelement(e).eleprof.range: 0
entityelement(e).eleprof.dropoff: 0
entityelement(e).eleprof.isviolent: 1
entityelement(e).eleprof.teamfield: 0
entityelement(e).eleprof.usespotlighting: 0
entityelement(e).eleprof.lodmodifier: 0
entityelement(e).eleprof.isocluder: 1
entityelement(e).eleprof.isocludee: 1
entityelement(e).eleprof.colondeath: 1
entityelement(e).eleprof.parententityindex: 0
entityelement(e).eleprof.parentlimbindex: 0
entityelement(e).eleprof.soundset2_s:
entityelement(e).eleprof.soundset3_s:
entityelement(e).eleprof.soundset4_s:
entityelement(e).eleprof.specularperc: 100
entityelement(e).iHasParentIndex: 0

+ Code Snippet

Versionnumberload: 312
g_entityelementlist: 2
entityelement(e).maintype: 1
entityelement(e).bankindex: 1
entityelement(e).staticflag: 1
entityelement(e).x: 25221.9824219
entityelement(e).y: 600
entityelement(e).z: 25702.9960938
entityelement(e).rx: 0
entityelement(e).ry: 0
entityelement(e).rz: 0
entityelement(e).eleprof.name_s: City Wall straight
entityelement(e).eleprof.aiinit_s: appear.lua
entityelement(e).eleprof.aimain_s: door.lua
entityelement(e).eleprof.aidestroy_s: disappear.lua
entityelement(e).eleprof.isobjective: 1
entityelement(e).eleprof.usekey_s:
entityelement(e).eleprof.ifused_s:
entityelement(e).eleprof.ifusednear_s:
entityelement(e).eleprof.uniqueelement: 0
entityelement(e).eleprof.texd_s: city_wall_tower_color.dds
entityelement(e).eleprof.texaltd_s:
entityelement(e).eleprof.effect_s: effectbank\reloaded\apbr_basic.fx
entityelement(e).eleprof.transparency: 0
entityelement(e).editorfixed: 0
entityelement(e).eleprof.soundset_s:
entityelement(e).eleprof.soundset1_s:
entityelement(e).eleprof.spawnmax: 0
entityelement(e).eleprof.spawndelay: 0
entityelement(e).eleprof.spawnqty: 0
entityelement(e).eleprof.hurtfall: 100
entityelement(e).eleprof.castshadow: 1
entityelement(e).eleprof.reducetexture: 0
entityelement(e).eleprof.speed: 100
entityelement(e).eleprof.aishoot_s:
entityelement(e).eleprof.hasweapon_s:
entityelement(e).eleprof.lives: 1
entityelement(e).spawn.max: 0
entityelement(e).spawn.delay: 0
entityelement(e).spawn.qty: 0
entityelement(e).eleprof.scale: 100
entityelement(e).eleprof.coneheight: 0
entityelement(e).eleprof.coneangle: 0
entityelement(e).eleprof.strength: 0
entityelement(e).eleprof.isimmobile: 1
entityelement(e).eleprof.cantakeweapon: 0
entityelement(e).eleprof.quantity: 4294967295
entityelement(e).eleprof.markerindex: 0
entityelement(e).eleprof.light.color: 4278190080
entityelement(e).eleprof.light.range: 0
entityelement(e).eleprof.trigger.stylecolor: 0
entityelement(e).eleprof.trigger.waypointzoneindex: 0
entityelement(e).eleprof.basedecal_s:
entityelement(e).eleprof.rateoffire: 85
entityelement(e).eleprof.damage: 0
entityelement(e).eleprof.accuracy: 0
entityelement(e).eleprof.reloadqty: 0
entityelement(e).eleprof.fireiterations: 0
entityelement(e).eleprof.lifespan: 0
entityelement(e).eleprof.throwspeed: 0
entityelement(e).eleprof.throwangle: 0
entityelement(e).eleprof.bounceqty: 0
entityelement(e).eleprof.explodeonhit: 0
entityelement(e).eleprof.weaponisammo: 0
entityelement(e).eleprof.spawnupto: 0
entityelement(e).eleprof.spawnafterdelay: 0
entityelement(e).eleprof.spawnwhendead: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.physics: 1
entityelement(e).eleprof.phyweight: 100
entityelement(e).eleprof.phyfriction: 100
entityelement(e).eleprof.phyforcedamage: 100
entityelement(e).eleprof.rotatethrow: 1
entityelement(e).eleprof.explodable: 0
entityelement(e).eleprof.explodedamage: 100
entityelement(e).eleprof.phydw4: 0
entityelement(e).eleprof.phydw5: 0
entityelement(e).eleprof.phyalways: 0
entityelement(e).eleprof.spawndelayrandom: 0
entityelement(e).eleprof.spawnqtyrandom: 0
entityelement(e).eleprof.spawnvel: 0
entityelement(e).eleprof.spawnvelrandom: 0
entityelement(e).eleprof.spawnangle: 0
entityelement(e).eleprof.spawnanglerandom: 0
entityelement(e).eleprof.spawnatstart: 1
entityelement(e).eleprof.spawnlife: 0
entityelement(e).eleprof.light.index: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
entityelement(e).eleprof.particleoverride: 1
entityelement(e).eleprof.particle.offsety: 0
entityelement(e).eleprof.particle.scale: 0
entityelement(e).eleprof.particle.randomstartx: 0
entityelement(e).eleprof.particle.randomstarty: 0
entityelement(e).eleprof.particle.randomstartz: 0
entityelement(e).eleprof.particle.linearmotionx: 0
entityelement(e).eleprof.particle.linearmotiony: 0
entityelement(e).eleprof.particle.linearmotionz: 0
entityelement(e).eleprof.particle.randommotionx: 0
entityelement(e).eleprof.particle.randommotiony: 0
entityelement(e).eleprof.particle.randommotionz: 0
entityelement(e).eleprof.particle.mirrormode: 0
entityelement(e).eleprof.particle.camerazshift: 0
entityelement(e).eleprof.particle.scaleonlyx: 0
entityelement(e).eleprof.particle.lifeincrement: 0
entityelement(e).eleprof.particle.alphaintensity: 0
entityelement(e).eleprof.particle.animated: 0
entityelement(e).eleprof.aiinitname_s:
entityelement(e).eleprof.aimainname_s:
entityelement(e).eleprof.aidestroyname_s:
entityelement(e).eleprof.aishootname_s:
entityelement(e).eleprof.animspeed: 100
entityelement(e).eleprof.conerange: 0
entityelement(e).scalex: 0
entityelement(e).scaley: 0
entityelement(e).scalez: 0
entityelement(e).eleprof.range: 0
entityelement(e).eleprof.dropoff: 0
entityelement(e).eleprof.isviolent: 1
entityelement(e).eleprof.teamfield: 0
entityelement(e).eleprof.usespotlighting: 0
entityelement(e).eleprof.lodmodifier: 0
entityelement(e).eleprof.isocluder: 1
entityelement(e).eleprof.isocludee: 1
entityelement(e).eleprof.colondeath: 1
entityelement(e).eleprof.parententityindex: 0
entityelement(e).eleprof.parentlimbindex: 0
entityelement(e).eleprof.soundset2_s:
entityelement(e).eleprof.soundset3_s:
entityelement(e).eleprof.soundset4_s:
entityelement(e).eleprof.specularperc: 100
entityelement(e).iHasParentIndex: 0
entityelement(e).maintype: 1
entityelement(e).bankindex: 2
entityelement(e).staticflag: 0
entityelement(e).x: 25135.5390625
entityelement(e).y: 600
entityelement(e).z: 25477.7734375
entityelement(e).rx: 0
entityelement(e).ry: 0
entityelement(e).rz: 0
entityelement(e).eleprof.name_s: Wizard
entityelement(e).eleprof.aiinit_s:
entityelement(e).eleprof.aimain_s: ai_neutral.lua
entityelement(e).eleprof.aidestroy_s:
entityelement(e).eleprof.isobjective: 0
entityelement(e).eleprof.usekey_s:
entityelement(e).eleprof.ifused_s:
entityelement(e).eleprof.ifusednear_s:
entityelement(e).eleprof.uniqueelement: 0
entityelement(e).eleprof.texd_s: wizard_D.dds
entityelement(e).eleprof.texaltd_s:
entityelement(e).eleprof.effect_s: effectbank\reloaded\character_basic.fx
entityelement(e).eleprof.transparency: 0
entityelement(e).editorfixed: 0
entityelement(e).eleprof.soundset_s: Male
entityelement(e).eleprof.soundset1_s:
entityelement(e).eleprof.spawnmax: 0
entityelement(e).eleprof.spawndelay: 0
entityelement(e).eleprof.spawnqty: 0
entityelement(e).eleprof.hurtfall: 100
entityelement(e).eleprof.castshadow: 0
entityelement(e).eleprof.reducetexture: 0
entityelement(e).eleprof.speed: 100
entityelement(e).eleprof.aishoot_s:
entityelement(e).eleprof.hasweapon_s: fantasy\staff
entityelement(e).eleprof.lives: 1
entityelement(e).spawn.max: 0
entityelement(e).spawn.delay: 0
entityelement(e).spawn.qty: 0
entityelement(e).eleprof.scale: 100
entityelement(e).eleprof.coneheight: 0
entityelement(e).eleprof.coneangle: 0
entityelement(e).eleprof.strength: 100
entityelement(e).eleprof.isimmobile: 0
entityelement(e).eleprof.cantakeweapon: 0
entityelement(e).eleprof.quantity: 0
entityelement(e).eleprof.markerindex: 0
entityelement(e).eleprof.light.color: 4278190080
entityelement(e).eleprof.light.range: 0
entityelement(e).eleprof.trigger.stylecolor: 0
entityelement(e).eleprof.trigger.waypointzoneindex: 0
entityelement(e).eleprof.basedecal_s:
entityelement(e).eleprof.rateoffire: 100
entityelement(e).eleprof.damage: 0
entityelement(e).eleprof.accuracy: 0
entityelement(e).eleprof.reloadqty: 0
entityelement(e).eleprof.fireiterations: 0
entityelement(e).eleprof.lifespan: 0
entityelement(e).eleprof.throwspeed: 0
entityelement(e).eleprof.throwangle: 0
entityelement(e).eleprof.bounceqty: 0
entityelement(e).eleprof.explodeonhit: 0
entityelement(e).eleprof.weaponisammo: 0
entityelement(e).eleprof.spawnupto: 0
entityelement(e).eleprof.spawnafterdelay: 0
entityelement(e).eleprof.spawnwhendead: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.spare1: 0
entityelement(e).eleprof.physics: 1
entityelement(e).eleprof.phyweight: 100
entityelement(e).eleprof.phyfriction: 100
entityelement(e).eleprof.phyforcedamage: 100
entityelement(e).eleprof.rotatethrow: 1
entityelement(e).eleprof.explodable: 0
entityelement(e).eleprof.explodedamage: 100
entityelement(e).eleprof.phydw4: 0
entityelement(e).eleprof.phydw5: 0
entityelement(e).eleprof.phyalways: 0
entityelement(e).eleprof.spawndelayrandom: 0
entityelement(e).eleprof.spawnqtyrandom: 0
entityelement(e).eleprof.spawnvel: 0
entityelement(e).eleprof.spawnvelrandom: 0
entityelement(e).eleprof.spawnangle: 0
entityelement(e).eleprof.spawnanglerandom: 0
entityelement(e).eleprof.spawnatstart: 1
entityelement(e).eleprof.spawnlife: 0
entityelement(e).eleprof.light.index: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
X10 elements: ignored in X9: 0
entityelement(e).eleprof.particleoverride: 1
entityelement(e).eleprof.particle.offsety: 0
entityelement(e).eleprof.particle.scale: 0
entityelement(e).eleprof.particle.randomstartx: 0
entityelement(e).eleprof.particle.randomstarty: 0
entityelement(e).eleprof.particle.randomstartz: 0
entityelement(e).eleprof.particle.linearmotionx: 0
entityelement(e).eleprof.particle.linearmotiony: 0
entityelement(e).eleprof.particle.linearmotionz: 0
entityelement(e).eleprof.particle.randommotionx: 0
entityelement(e).eleprof.particle.randommotiony: 0
entityelement(e).eleprof.particle.randommotionz: 0
entityelement(e).eleprof.particle.mirrormode: 0
entityelement(e).eleprof.particle.camerazshift: 0
entityelement(e).eleprof.particle.scaleonlyx: 0
entityelement(e).eleprof.particle.lifeincrement: 0
entityelement(e).eleprof.particle.alphaintensity: 0
entityelement(e).eleprof.particle.animated: 0
entityelement(e).eleprof.aiinitname_s:
entityelement(e).eleprof.aimainname_s:
entityelement(e).eleprof.aidestroyname_s:
entityelement(e).eleprof.aishootname_s:
entityelement(e).eleprof.animspeed: 100
entityelement(e).eleprof.conerange: 0
entityelement(e).scalex: 0
entityelement(e).scaley: 0
entityelement(e).scalez: 0
entityelement(e).eleprof.range: 0
entityelement(e).eleprof.dropoff: 0
entityelement(e).eleprof.isviolent: 1
entityelement(e).eleprof.teamfield: 0
entityelement(e).eleprof.usespotlighting: 0
entityelement(e).eleprof.lodmodifier: 0
entityelement(e).eleprof.isocluder: 1
entityelement(e).eleprof.isocludee: 1
entityelement(e).eleprof.colondeath: 1
entityelement(e).eleprof.parententityindex: 0
entityelement(e).eleprof.parentlimbindex: 0
entityelement(e).eleprof.soundset2_s:
entityelement(e).eleprof.soundset3_s:
entityelement(e).eleprof.soundset4_s:
entityelement(e).eleprof.specularperc: 100
entityelement(e).iHasParentIndex: 0

Professional Programmer: Languages- SAS (Statistical Analysis Software) , C++, C#, VB, SQL, PL-SQL, JavaScript, HTML, Three.js, Darkbasic Pro (still love this language), Purebasic, others
Hardware: Dell Precision 490; AMD Radeon HD 7570; 12GB.

PM Website

DVader

20

Years of Service

User Offline

Joined: 28th Jan 2004

Location:

Profile

Posted: 19th May 2019 15:37 Edited at: 19th May 2019 16:07

Link

Not used Dark Basic in a few years either. Seem to remember it having issues on newer Operating systems, so tend to use AGK for anything these days. That's still a big file it's going through! Is Dark Basic working okay these days? I had issues with some of my old games not working on newer versions of windows as I remember. Also have you noticed it doing anything it shouldn't to the files you tested? I'd either have to get DB again or convert it to work with AGK (probably needs a few different command names mainly). Probably easier to find DB out

I did sit down to do some programming yesterday but wanted to try something first and ended up working on that all night. It wasn't what I had originally sat down to do, but found it quite amusing, watching the computer do it's thing, lol.

All done by the computer

Amazing what can be done with random and a few bits of code. I saved this image as I was quite impressed considering how simple the code was. Easy to get distracted sometimes

SPECS: Ryzen 1700 CPU. Nvidia 970GTX. 16 Gig Memory. Win 10.

Attachments

Login to view attachments

PM Website

Bored of the Rings

GameGuru Master

19

Years of Service

User Offline

Joined: 25th Feb 2005

Location: Middle Earth

Profile

Posted: 19th May 2019 16:19

Link

@Dvader-I use C+, DB , AGK and sometime Purebasic. I will be writing a version for AGK as I'm getting more into that lately but still use DBPro to work stuff out quickly. Not noticed anything unusual yet about the the map file but will check it out a bit more. DBPro works fine and is great with Matrix1Utils. Love the pic, looks crazy ha

Professional Programmer: Languages- SAS (Statistical Analysis Software) , C++, C#, VB, SQL, PL-SQL, JavaScript, HTML, Three.js, Darkbasic Pro (still love this language), Purebasic, others
Hardware: Dell Precision 490; AMD Radeon HD 7570; 12GB.

PM Website

Bored of the Rings

GameGuru Master

19

Years of Service

User Offline

Joined: 25th Feb 2005

Location: Middle Earth

Profile

Posted: 24th May 2019 14:02

Link

ok so I have now successfully ported lights/markers etc into GameGuru automatically upon loading a GG formatted FPM file (see pics below). This is for my ongoing AutoWelder project bringing in FPSC levels to GameGuru + entities etc. my findings are that issue was that "Read File" in the source code was being used to read in DWORDs (4 bytes) instead of reading in LONGs (even though READ FILE defaults to 4 bytes or DWORD/LONG-bug maybe?). Anyway, I'm still investigating but there may be some issues with the reading/writing of the mapsave files but don't want to jump to conclusions just yet.

Professional Programmer: Languages- SAS (Statistical Analysis Software) , C++, C#, VB, SQL, PL-SQL, JavaScript, HTML, Three.js, Darkbasic Pro (still love this language), Purebasic, others
Hardware: Dell Precision 490; AMD Radeon HD 7570; 12GB.

Attachments

Login to view attachments

PM Website

Product Chat / Investigating the Map Save File

Attachments

Attachments
