//Description:  Shader for dynamic entities, normal mapping,specular, reflectivity,

// and "hero" spec that always faces player.  "LightSource" variable is pulled from FPSC for accurate lighting.

//

//Textures:

//"texture_D.dds"      diffuse texture

//"texture_I.dd"       specular texture, alpha channel is reflectivity mask

//"texture_N.dds"       normal map texture

//"texture_S.dds"       reflectivity texture

/************* UNTWEAKABLES **************/



float4x4 World      : WORLD;



float4x4 WorldViewProj : WorldViewProjection;

float4x4 WorldIT : WorldInverseTranspose;

float4x4 ViewInv : ViewInverse;

float4 eyePos : CameraPosition;

float time: Time;









/******TWEAKABLES***************************/



float SpecExpon : Power

<

    string UIWidget = "slider";

    float UIMin = 1.0;

    float UIMax = 128.0;

    float UIStep = 1.0;

    string UIName =  "specular power";

> = 64.0;





/******VALUES PULLED FROM FPSC - NON TWEAKABLE**********/



float4 AmbiColor : Ambient

<

    string UIName =  "Ambient Light Color";

> = {0.1f, 0.1f, 0.1f, 1.0f};



float4 SurfColor : Diffuse

<

    string UIName =  "Surface Color";

    string UIType = "Color";

> = {0.50f, 0.50f, 0.50f, 1.0f};



float4 LightSource

<

    string UIType = "Fixed Light Source";

> = {50000.0f,50000.0f, -0.0f, 1.0f};









/****************** TEXTURES AND SAMPLERS*********************/







texture DiffuseMap : DiffuseMap

<

    string Name = "D.tga";

    string type = "2D";

>;



//could be anything here - ill,spec,normal,cube

texture EffectMap : DiffuseMap

<

    string Name = "I.tga";

    string type = "2D";

>;



texture NormalMap : DiffuseMap

<

    string Name = "N.tga";

    string type = "2D";

>;

texture EnvironmentMap

<

    string type = "2D";

    string name = "i.tga";

>;













//Diffuse Texture _D

sampler2D DiffuseSampler = sampler_state

{

    Texture   = <DiffuseMap>;

    MipFilter = LINEAR;

    MinFilter = LINEAR;

    MagFilter = LINEAR;

    AddressU = WRAP;

	AddressV = WRAP;



};



//Effect Texture _I (could be anything here - ill,spec,normal,cube)

sampler2D EffectSampler = sampler_state

{

    Texture   = <EffectMap>;

    MipFilter = LINEAR;

    MinFilter = LINEAR;

    MagFilter = LINEAR;

    AddressU = WRAP;

	AddressV = WRAP;



};



//Effect Texture _N (could be anything here - ill,spec,normal,cube)

sampler2D NormalSampler = sampler_state

{

    Texture   = <NormalMap>;

    MipFilter = LINEAR;

    MinFilter = LINEAR;

    MagFilter = LINEAR;

    AddressU = WRAP;

	AddressV = WRAP;



};



//Effect Texture _S   fake cubemap texture (blurred 2d image)

sampler EnvironmentSampler = sampler_state

{

    Texture = (EnvironmentMap);

    MipFilter = LINEAR;

    MinFilter = LINEAR;

    MagFilter = LINEAR;

    AddressU = WRAP;

	AddressV = WRAP;



};



;











/************* DATA STRUCTS **************/



struct appdata {

    float4 Position	: POSITION;

    float4 UV0		: TEXCOORD0;

    float4 Normal	: NORMAL;

    float4 Tangent	: TANGENT0;

    float4 Binormal	: BINORMAL0;

};







/*data passed to pixel shader*/

struct vertexOutput

{

    float4 Position    : POSITION;

    float2 TexCoord     : TEXCOORD0;

    float3 LightVec	    : TEXCOORD2;

    float3 WorldNormal	: TEXCOORD3;

    float3 WorldTangent	: TEXCOORD4;

    float3 WorldBinorm	: TEXCOORD5;

    float4 WPos : TEXCOORD6;





};





/*******Vertex Shader***************************/



vertexOutput mainVS(appdata IN)

{



	vertexOutput OUT;



    //float4 tempPos = float4(IN.Position, 1);

    float4 worldSpacePos = mul(IN.Position, World);



    OUT.WorldNormal = normalize(mul(IN.Normal, WorldIT).xyz);

    OUT.WorldTangent = mul(IN.Tangent, WorldIT).xyz;

    OUT.WorldBinorm = mul(IN.Binormal, WorldIT).xyz;





    OUT.LightVec = normalize (LightSource - worldSpacePos );

    OUT.Position = mul(IN.Position, WorldViewProj);

    OUT.TexCoord  = IN.UV0;



    OUT.WPos =   worldSpacePos;





	/*******************************************************************************************/





    return OUT;

}





/****************Framgent Shader*****************/



float4 mainPS(vertexOutput IN) : COLOR

{



    //Code chunk to keep time value from getting too high/////////////////////

    float looptime = 190; //looptime in seconds

	float loopcounter  = floor(time/looptime); //increments by one every 190 seconds (or whatever "looptime" is)

	float offset ;  //initialize offset value used below

	offset = looptime*loopcounter; //offset time value -increments every looptime

	float speed =(time) - (offset) ;

    ///////////////////////////////////////////////////////////////////////////



    //scrolling the uv coordinates

    float2 scroll = IN.TexCoord + float2(-0.0,-0.1)*speed;



    float4 diffuse = tex2D(DiffuseSampler,scroll.xy);    //sample diffuse texture

    float4 effectmap = tex2D(EffectSampler,IN.TexCoord.xy);    //sample specular map texture

    float3 normalmap = tex2D(NormalSampler,scroll.xy) *0-1 ;  //sample and expand normal map



    float3 Ln = (IN.LightVec);

    float3 Nn = normalize(IN.WorldNormal);

    float3 Tn = normalize(IN.WorldTangent);

    float3 Bn = normalize(IN.WorldBinorm);

    float3 Nb = (normalmap.z * Nn) + (1.0*(normalmap.x * Tn + normalmap.y * Bn));

    Nb = normalize(Nb);







    //normalized view vector for accurate specular highlights from LightSource

    float3 ViewVector  = (eyePos - IN.WPos);

    float3 Vn = normalize(ViewVector);





    //reflection mapping for windows and flat surfaces

    float3 G = normalize(2 * dot(Nb, Vn) * Nb - Vn);                // glance vector (view space)

    float3 Reflection = float3(-G.x, G.y, -G.z);

    float4 Env = texCUBE(EnvironmentSampler,Reflection);





    //half vectors

    float3 Hn = normalize(Vn+Ln);





   //calculate lighting Half Lamert scale and bias

    //float4 lighting = lit(pow(0.5*(dot(Ln,Nb))+0.5,1.0),dot(Hn,Nb),24);

    float4 spec = pow(max(dot(Nb,Hn),0),24);











    //specular light contribution

    float4 specContrib = spec * effectmap ;



    //Cubemap reflection contribution

    float4 Reflectivity = Env;





    float4 result =  (0.6*diffuse*SurfColor)+(0.4*Reflectivity)+1.5*specContrib;



    result.w = 0.5 * diffuse.w;













    return result;

}





/****** technique ********************************/



technique dx9textured

{

    pass P0

    {

        // lighting

        Lighting       = FALSE;

        FogEnable      = FALSE;





        // samplers

        //Sampler[0] = (LightmapSampler);

        //Sampler[1] = (DiffuseSampler);

        //Sampler[2] = (IllSpecSampler);

		//Sampler[3] = (NormalSampler);



        // shaders

        VertexShader = compile vs_2_0 mainVS();

        PixelShader  = compile ps_2_0 mainPS();

    }

}
